OEM#: LRTZ303531New OEM Original Outright
INNER RING FOR MACHINED TYPE NEEDLE ROLLER BEARING METRIC, 30MM BORE, 35MM OD, 31MM WIDTH by IKO International
Your price:
$42.44 each
OEM#: LRTZ303531INNER RING FOR MACHINED TYPE NEEDLE ROLLER BEARING METRIC, 30MM BORE, 35MM OD, 31MM WIDTH by IKO International
New OEM Original Outright
Your price:
$42.44 each
Asset Information
Must purchase minimum of 2
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
IKO Inner Ring for Machined Type Needle Roller Bearing METRIC, 30mm Bore, 35mm OD, 31mm Width
IKO Inner Rings are heat-treated and finished by grinding to obtain rigidity and accuracy. Use IKO Inner Rings when shafts cannot be hardened to HRC 58 to 64 and cannot obtain 0.2μmRa or less surface finish. Shaft shoulder "da" is found in the main page of IKO Inner Rings.
IKO Inner Rings are heat-treated and finished by grinding to obtain rigidity and accuracy. Use IKO Inner Rings when shafts cannot be hardened to HRC 58 to 64 and cannot obtain 0.2μmRa or less surface finish. Shaft shoulder "da" is found in the main page of IKO Inner Rings.
Technical Specs
P/N: LRTZ303531 Key Specs
Item
INNER RING FOR MACHINED TYPE NEEDLE ROLLER BEARING METRIC, 30MM BORE, 35MM OD, 31MM WIDTH
OEM
IKO International
OEM #
LRTZ303531
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Appropriate Outer Ring
RNA6906UU
Bore (D) Mm
30
Bore Tolerance (Mm)
+0 / -0.010
Country of Origin
Japan
Inner Ring Corner Radius Min (Mm)
0.3
O.D. Tolerance (Mm)
+0.005 / -0.004
Od (F) Mm
35
Series
LRTZ
Shaft Shoulder (Da) Max (Mm)
34
Shaft Shoulder (Da) Min (Mm)
32
Width (B) Mm
31
Width Tolerance (Mm)
+0 / -0.120
IKO Inner Ring for Machined Type Needle Roller Bearing METRIC, 30mm Bore, 35mm OD, 31mm Width
IKO Inner Rings are heat-treated and finished by grinding to obtain rigidity and accuracy. Use IKO Inner Rings when shafts cannot be hardened to HRC 58 to 64 and cannot obtain 0.2μmRa or less surface finish. Shaft shoulder "da" is found in the main page of IKO Inner Rings.
IKO Inner Rings are heat-treated and finished by grinding to obtain rigidity and accuracy. Use IKO Inner Rings when shafts cannot be hardened to HRC 58 to 64 and cannot obtain 0.2μmRa or less surface finish. Shaft shoulder "da" is found in the main page of IKO Inner Rings.
