OEM#: LRT9010050New OEM Original Outright
INNER RING FOR MACHINED TYPE NEEDLE ROLLER BEARING METRIC, 90MM BORE, 100MM OD, 50.5MM WIDTH by IKO International
Your price:
$162.06 each
OEM#: LRT9010050INNER RING FOR MACHINED TYPE NEEDLE ROLLER BEARING METRIC, 90MM BORE, 100MM OD, 50.5MM WIDTH by IKO International
New OEM Original Outright
Your price:
$162.06 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
IKO Inner Ring for Machined Type Needle Roller Bearing METRIC, 90mm Bore, 100mm OD, 50.5mm Width
IKO Inner Rings are heat-treated and finished by grinding to obtain rigidity and accuracy. Use IKO Inner Rings when shafts cannot be hardened to HRC 58 to 64 and cannot obtain 0.2μmRa or less surface finish. Shaft shoulder "da" is found in the main page of IKO Inner Rings.
IKO Inner Rings are heat-treated and finished by grinding to obtain rigidity and accuracy. Use IKO Inner Rings when shafts cannot be hardened to HRC 58 to 64 and cannot obtain 0.2μmRa or less surface finish. Shaft shoulder "da" is found in the main page of IKO Inner Rings.
Technical Specs
P/N: LRT9010050 Key Specs
Item
INNER RING FOR MACHINED TYPE NEEDLE ROLLER BEARING METRIC, 90MM BORE, 100MM OD, 50.5MM WIDTH
OEM
IKO International
OEM #
LRT9010050
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Appropriate Outer Ring
TR10012550
Bore (D) (mm)
90
Bore Tolerance (mm)
+0 / -0.020
Country of Origin
Japan
Maximum Shaft Shoulder (da) (mm)
98.5
Minimum Inner Ring Corner Radius (mm)
1.5
Minimum Shaft Shoulder (da) (mm)
98
OD (F) (mm)
100
OD Tolerance (mm)
-0.014 / -0.027
Series
LRT
Width (B) (mm)
50.5
Width Tolerance (mm)
+0 / -0.200
IKO Inner Ring for Machined Type Needle Roller Bearing METRIC, 90mm Bore, 100mm OD, 50.5mm Width
IKO Inner Rings are heat-treated and finished by grinding to obtain rigidity and accuracy. Use IKO Inner Rings when shafts cannot be hardened to HRC 58 to 64 and cannot obtain 0.2μmRa or less surface finish. Shaft shoulder "da" is found in the main page of IKO Inner Rings.
IKO Inner Rings are heat-treated and finished by grinding to obtain rigidity and accuracy. Use IKO Inner Rings when shafts cannot be hardened to HRC 58 to 64 and cannot obtain 0.2μmRa or less surface finish. Shaft shoulder "da" is found in the main page of IKO Inner Rings.
