OEM#: LRT172116New OEM Original Outright
INNER RING FOR MACHINED TYPE NEEDLE ROLLER BEARING METRIC, 17MM BORE, 21MM OD, 16MM WIDTH by IKO International
Your price:
$12.97 each
OEM#: LRT172116INNER RING FOR MACHINED TYPE NEEDLE ROLLER BEARING METRIC, 17MM BORE, 21MM OD, 16MM WIDTH by IKO International
New OEM Original Outright
Your price:
$12.97 each
Asset Information
Must purchase minimum of 6
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
IKO Inner Ring for Machined Type Needle Roller Bearing METRIC, 17mm Bore, 21mm OD, 16mm Width
IKO Inner Rings are heat-treated and finished by grinding to obtain rigidity and accuracy. Use IKO Inner Rings when shafts cannot be hardened to HRC 58 to 64 and cannot obtain 0.2μmRa or less surface finish. Shaft shoulder "da" is found in the main page of IKO Inner Rings.
IKO Inner Rings are heat-treated and finished by grinding to obtain rigidity and accuracy. Use IKO Inner Rings when shafts cannot be hardened to HRC 58 to 64 and cannot obtain 0.2μmRa or less surface finish. Shaft shoulder "da" is found in the main page of IKO Inner Rings.
Technical Specs
P/N: LRT172116 Key Specs
Item
INNER RING FOR MACHINED TYPE NEEDLE ROLLER BEARING METRIC, 17MM BORE, 21MM OD, 16MM WIDTH
OEM
IKO International
OEM #
LRT172116
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Appropriate Outer Ring
TAF212916
Bore (D) Mm
17
Bore Tolerance (Mm)
+0 / -0.008
Country of Origin
Japan
Inner Ring Corner Radius Min (Mm)
0.3
O.D. Tolerance (Mm)
+0 / -0.012
Od (F) Mm
21
Series
LRT
Shaft Shoulder (Da) Max (Mm)
20
Shaft Shoulder (Da) Min (Mm)
19
Width (B) Mm
16
Width Tolerance (Mm)
+0 / -0.120
IKO Inner Ring for Machined Type Needle Roller Bearing METRIC, 17mm Bore, 21mm OD, 16mm Width
IKO Inner Rings are heat-treated and finished by grinding to obtain rigidity and accuracy. Use IKO Inner Rings when shafts cannot be hardened to HRC 58 to 64 and cannot obtain 0.2μmRa or less surface finish. Shaft shoulder "da" is found in the main page of IKO Inner Rings.
IKO Inner Rings are heat-treated and finished by grinding to obtain rigidity and accuracy. Use IKO Inner Rings when shafts cannot be hardened to HRC 58 to 64 and cannot obtain 0.2μmRa or less surface finish. Shaft shoulder "da" is found in the main page of IKO Inner Rings.
