OEM#: KT697NC3New OEM Original Outright
NEEDLE ROLLER CAGE ASSEMBLY, 6MM BORE, 9MM OD, 7MM W, SYNTHETIC CAGE MATERIAL by IKO International
Your price:
$16.73 each
OEM#: KT697NC3NEEDLE ROLLER CAGE ASSEMBLY, 6MM BORE, 9MM OD, 7MM W, SYNTHETIC CAGE MATERIAL by IKO International
New OEM Original Outright
Your price:
$16.73 each
Asset Information
Must purchase minimum of 5
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
IKO Needle Roller Cage Assembly, 6mm Bore, 9mm OD, 7mm Width, Synthetic Cage Material
IKO Needle Roller Cage Assembly consists of needle rollers with extremely high accuracy and specially designed cage. These products are suitable to use in limited spaces, combining with shafts and housings. 0.2µmRa or less surface finish and HRC 58 to 64 hardness are recommended for the shaft and housing. If the surface hardness is low, load ratings become lower than values described. Due to their lightweight, high rigidity and lubricant holding design, these products can withstand severe operating conditions such as high speed and shock load.
IKO Needle Roller Cage Assembly consists of needle rollers with extremely high accuracy and specially designed cage. These products are suitable to use in limited spaces, combining with shafts and housings. 0.2µmRa or less surface finish and HRC 58 to 64 hardness are recommended for the shaft and housing. If the surface hardness is low, load ratings become lower than values described. Due to their lightweight, high rigidity and lubricant holding design, these products can withstand severe operating conditions such as high speed and shock load.
Technical Specs
P/N: KT697NC3 Key Specs
Item
NEEDLE ROLLER CAGE ASSEMBLY, 6MM BORE, 9MM OD, 7MM W, SYNTHETIC CAGE MATERIAL
OEM
IKO International
OEM #
KT697NC3
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bore (Fw) Mm/Inch
6
Bore (Mm)
+0.014 / +0.005
Cage Material
Synthetic
Country of Origin
Japan
Dynamic Load Rating (N)
2310
Max Speed / Grease (Rpm)
37500
Max Speed / Oil (Rpm)
75000
Od (Ew) (Mm)
9
Series
KT
Shaft Diameter Mm
+0 / -0.005
Static Load Rating (N)
1900
Temperature Range C
-20 to +110
Tolerance Cage Width (Mm)
-0.20 / -0.55
Tolerance Roller Diameter (Mm)
+0 / -0.003
Width (Bc) (Mm)
7
IKO Needle Roller Cage Assembly, 6mm Bore, 9mm OD, 7mm Width, Synthetic Cage Material
IKO Needle Roller Cage Assembly consists of needle rollers with extremely high accuracy and specially designed cage. These products are suitable to use in limited spaces, combining with shafts and housings. 0.2µmRa or less surface finish and HRC 58 to 64 hardness are recommended for the shaft and housing. If the surface hardness is low, load ratings become lower than values described. Due to their lightweight, high rigidity and lubricant holding design, these products can withstand severe operating conditions such as high speed and shock load.
IKO Needle Roller Cage Assembly consists of needle rollers with extremely high accuracy and specially designed cage. These products are suitable to use in limited spaces, combining with shafts and housings. 0.2µmRa or less surface finish and HRC 58 to 64 hardness are recommended for the shaft and housing. If the surface hardness is low, load ratings become lower than values described. Due to their lightweight, high rigidity and lubricant holding design, these products can withstand severe operating conditions such as high speed and shock load.
