OEM#: IRT3530New OEM Original Outright
INNER RING FOR SHELL TYPE NEEDLE ROLLER BEARING METRIC, 35MM BORE, 40MM OD, 30.5MM WIDTH by IKO International
Your price:
$34.18 each
OEM#: IRT3530INNER RING FOR SHELL TYPE NEEDLE ROLLER BEARING METRIC, 35MM BORE, 40MM OD, 30.5MM WIDTH by IKO International
New OEM Original Outright
Your price:
$34.18 each
Asset Information
Must purchase minimum of 2
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
IKO Inner Ring for Shell Type Needle Roller Bearing METRIC, 35mm Bore, 40mm OD, 30.5mm Width, Part# IRT3530
IKO Inner Rings are heat-treated and finished by grinding to obtain rigidity and accuracy.
Use IKO Inner Rings when shafts cannot be hardened to HRC 58 to 64 and cannot obtain 0.2μmRa or less surface finish.
IKO Inner Rings are heat-treated and finished by grinding to obtain rigidity and accuracy.
Use IKO Inner Rings when shafts cannot be hardened to HRC 58 to 64 and cannot obtain 0.2μmRa or less surface finish.
Technical Specs
P/N: IRT3530 Key Specs
Item
INNER RING FOR SHELL TYPE NEEDLE ROLLER BEARING METRIC, 35MM BORE, 40MM OD, 30.5MM WIDTH
OEM
IKO International
OEM #
IRT3530
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Appropriate Outer Ring
TA4030Z
Bore (D) Mm
35
Bore Tolerance (Mm)
+0 / -0.012
Country of Origin
Japan
Inner Ring Corner Radius Min (Mm)
0.6
O.D. Tolerance (Mm)
-0.009 / -0.020
Od (F) Mm
40
Shaft Shoulder (Da) Max (Mm)
39.5
Shaft Shoulder (Da) Min (Mm)
39
Width (B) Mm
30.5
Width Tolerance (Mm)
+0 / -0.120
IKO Inner Ring for Shell Type Needle Roller Bearing METRIC, 35mm Bore, 40mm OD, 30.5mm Width, Part# IRT3530
IKO Inner Rings are heat-treated and finished by grinding to obtain rigidity and accuracy.
Use IKO Inner Rings when shafts cannot be hardened to HRC 58 to 64 and cannot obtain 0.2μmRa or less surface finish.
IKO Inner Rings are heat-treated and finished by grinding to obtain rigidity and accuracy.
Use IKO Inner Rings when shafts cannot be hardened to HRC 58 to 64 and cannot obtain 0.2μmRa or less surface finish.
