OEM#: CRY24VUUNew OEM Original Outright
ROLLER FOLLOWER- FULL COMP- INCH, DOUBLE SEALED, 1-1/2" OD by IKO International
Your price:
$40.08 each
OEM#: CRY24VUUROLLER FOLLOWER- FULL COMP- INCH, DOUBLE SEALED, 1-1/2" OD by IKO International
New OEM Original Outright
Your price:
$40.08 each
Asset Information
Must purchase minimum of 2
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
IKO Roller Follower- Full Comp- Inch, CRY24VUU, Double Sealed, 1-1/2" OD
IKO Non-separable Yoke Type Roller Follower is full complement bearing with inner ring, side plates and thick-walled outer ring to withstand heavy rolling or shock loads. Its surface is treated with black oxide coating. Roller Followers are available with Crowned or Cylindrical outer rings. The crowned outer ring relieves edge load created by mounting error and the cylindrical is suitable for applications with large loads or low track surface hardness due to a large contact area with mating track surface. Sufficient lubrication is needed between roller followers and steel track on which cam followers run, to prevent seizure and to reduce friction.
IKO Non-separable Yoke Type Roller Follower is full complement bearing with inner ring, side plates and thick-walled outer ring to withstand heavy rolling or shock loads. Its surface is treated with black oxide coating. Roller Followers are available with Crowned or Cylindrical outer rings. The crowned outer ring relieves edge load created by mounting error and the cylindrical is suitable for applications with large loads or low track surface hardness due to a large contact area with mating track surface. Sufficient lubrication is needed between roller followers and steel track on which cam followers run, to prevent seizure and to reduce friction.
Technical Specs
P/N: CRY24VUU Key Specs
Item
ROLLER FOLLOWER- FULL COMP- INCH, DOUBLE SEALED, 1-1/2" OD
OEM
IKO International
OEM #
CRY24VUU
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bearing Style
Cylindrical OD
Bore Diameter (mm/in)
11.112 (7/16)
Bore Tolerance (mm)
+0.005 / -0.010
Country of Origin
Japan
Dynamic Load Rating (N)
28200
Minimum Outer Ring Corner Radius (mm (in))
1.588 (1/16)
Needle Construction
Full Compliment
OD (mm (in))
38.100 (1-1/2)
OD Tolerance (mm)
+0 / -0.025
Oil Hole & Groove
At inner ring
Outer Ring Width (mm (in))
22.225 (7/8)
Overall Width (mm/in)
23.813 (.9375)
Prepacked Grease
YES
Radial Clearance
0.035 to 0.060
Retainer
None
Series
CRY
Shaft Diameter Drive Fit (mm)
11.110 to 11.120
Shaft Diameter Press Fit (mm)
11.115 to 11.125
Shaft Diameter Push Fit (mm)
11.095 to 11.105
Side Plate OD (A) (mm (in))
28.8 (1.134)
Static Load Rating (N)
40100
Tolerance Outer Ring Width (mm)
+0 / -0.130
Tolerance Overall Width (mm)
+0.130 / -0.250
Track Capacity (N)
15400
Type
Double Sealed
IKO Roller Follower- Full Comp- Inch, CRY24VUU, Double Sealed, 1-1/2" OD
