OEM#: RJUI-01-10New OEM Original Outright

5/8" DRYLIN R POLYMER LINEAR BEARING WITH SHELL by igus

Your price:
$20.49 eachReady to ship
Homeigusrjui0110
5/8" DRYLIN R POLYMER LINEAR BEARING WITH SHELL by igus
5/8" DRYLIN R POLYMER LINEAR BEARING WITH SHELL by igus

OEM#: RJUI-01-10
5/8" DRYLIN R POLYMER LINEAR BEARING WITH SHELL by igus

New OEM Original Outright
Your price:
$20.49 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
5/8" DryLin R Polymer Linear Bearing with Shell

Special Features:
  • Anodized aluminum adapter
  • Dimensionally interchangeable with recirculating ball bushings
  • Equipped with liner made from iglide® J
  • Temperature range -40°F to +194°F JUI-01 (standard), JUI-20 (low clearance)
    *T500 liner optional for chemicals/high temps (up to 482°F for steel housing, 356°F for aluminum)
  • Suitable shafting for iglide® J: DryLin® AWI aluminum, case-hardened, 300 series
  • Best shafting for T500: hard-chrome and hard stainless steel
Technical Specs
P/N: RJUI-01-10 Key Specs
Item
5/8" DRYLIN R POLYMER LINEAR BEARING WITH SHELL
OEM
igus
OEM #
RJUI-01-10
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Diagram Dimension D2
2
Diagram Dimension Dn
1.0600
Diagram Dimension Do
.9620
Diagram Dimension E
0.312
Diagram Dimension S
.0620
Dimension B
1.5000
Dimension B1
1.1240
Dimension O
.1250
Dynamic Load Lbs.
338
Manufacturer Name
igus, Inc.
Max. Temperature
194°F
Nominal Size Inches
2
Static Load Lbs.
2365
Tolerance
0.0016-0.0032
5/8" DryLin R Polymer Linear Bearing with Shell
