OEM#: TW-04-09New OEM Original Outright
DRYLIN-T POLYMER-LINED MINI PROFILE GUIDE - SIZE 9 by igus
Your price:
$35.08 each
OEM#: TW-04-09DRYLIN-T POLYMER-LINED MINI PROFILE GUIDE - SIZE 9 by igus
New OEM Original Outright
Your price:
$35.08 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
DryLin-T Polymer-Lined Mini Profile Guide - Size 9
- Maintenance-free, dry operation
- Three sizes
- Simple installation
- Cast zinc chromated carriage
- Replaceable, wear-resistant iglide® J plastic sliding pads
- Hard-anodized aluminum rails
- Small mounting height and width
- Corrosion Resistant
- Standard bore pattern symmetrical C5 = C6
Technical Specs
P/N: TW-04-09 Key Specs
Item
DRYLIN-T POLYMER-LINED MINI PROFILE GUIDE - SIZE 9
OEM
igus
OEM #
TW-04-09
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Co-Y (Kn)
0.48
Coy (Kn)
.48
Coz (Kn)
.24
Dimension A
20
Dimension A1
5.5
Dimension A2
15
Dimension C
42
Dimension C1
18
Dimension C2
13
Dimension H
10
Dimension H1
1.7
Dimension H5
7.2
K2 Thread
M2
K3 For Screw (Din 912)
M2
Manufacturer Name
igus, Inc.
Mox (Nm)
3.4
Moy (Nm)
1.8
Moz (Nm)
1.8
Temperature (°F)
-40 to 194
Torque Max. (Nm)
25
DryLin-T Polymer-Lined Mini Profile Guide - Size 9
- Maintenance-free, dry operation
- Three sizes
- Simple installation
- Cast zinc chromated carriage
- Replaceable, wear-resistant iglide® J plastic sliding pads
- Hard-anodized aluminum rails
- Small mounting height and width
- Corrosion Resistant
- Standard bore pattern symmetrical C5 = C6
