OEM#: RJUI-11-12New OEM Original Outright
3/4" DRYLIN R BEARING BLOCK WITH POLYMER LINER by igus
Your price:
$89.48 each
OEM#: RJUI-11-123/4" DRYLIN R BEARING BLOCK WITH POLYMER LINER by igus
New OEM Original Outright
Your price:
$89.48 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
3/4" DryLin R Bearing Block with Polymer Liner
Special Properties:
- Closed, anodized aluminum housing
- Liner JUI-01 made from iglide® J contained according to standard tolerances
- Can be fitted with T500 liner material for temperatures up to 356°F
- Low clearance liners optional
Technical Specs
P/N: RJUI-11-12 Key Specs
Item
3/4" DRYLIN R BEARING BLOCK WITH POLYMER LINER
OEM
igus
OEM #
RJUI-11-12
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Dimension A
0.937
Dimension B
2.75
Dimension C
1.938
Dimension D
1.75
Dimension E
2.375
Dimension F
1.25
Dimension G
1.875
Dimension J
0.313
Dimension K
2.063
Dimension M
1.625
Dimension O
0.056
Dimension P
1.33
Dynamic Load Lbs.
439
H Bolt/Hole
#8 3/16
Manufacturer Name
igus, Inc.
Nominal Size Inches
1-1/4
Static Load Lbs.
3077
Temperature (°F)
-40 to 194
