OEM#: PRT-02-30-ALNew OEM Original Outright
100MM DIA. SLEWING RING BEARING - 5,620 LBS MAX AXIAL STATIC by igus
Your price:
$204.14 each
OEM#: PRT-02-30-AL100MM DIA. SLEWING RING BEARING - 5,620 LBS MAX AXIAL STATIC by igus
New OEM Original Outright
Your price:
$204.14 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
100mm Dia. Slewing Ring Bearing - 5,620 lbs Max Axial Static
iglide® PRT is a slewing ring bearing with the proven advantage of igus® plastic bearings. The iglide® J sliding elements are completely maintenance-free and lubrication-free. All the housing components are made of aluminum (except style 02, which has iglide® J4 head rings), and all the parallel surfaces of iglide® J sliding elements are hard anodized. All the fixing screws are made of stainless steel. The PRT slewing rings are available on request in stainless steel.
iglide® PRT is a slewing ring bearing with the proven advantage of igus® plastic bearings. The iglide® J sliding elements are completely maintenance-free and lubrication-free. All the housing components are made of aluminum (except style 02, which has iglide® J4 head rings), and all the parallel surfaces of iglide® J sliding elements are hard anodized. All the fixing screws are made of stainless steel. The PRT slewing rings are available on request in stainless steel.
Technical Specs
P/N: PRT-02-30-AL Key Specs
Item
100MM DIA. SLEWING RING BEARING - 5,620 LBS MAX AXIAL STATIC
OEM
igus
OEM #
PRT-02-30-AL
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Color
Metal/Grey
Dimension A
15
Dimension D
100mm
Dimension D1
42.5
Dimension D2
80
Dimension H
6
Dimension K2
DIN 439 M5A2
Dimension S2
4.5
Dimension T1
8 x 45°
Dimension T2
8 x 45°
K1 Screw (Din912)
DIN 7984 M5
Manufacturer Name
igus, Inc.
Max Axial Dynamic
1,573 lbs.
Max Axial Static
5,620 lbs.
Max Radial Dynamic
157 lbs.
Max Radial Static
562 lbs.
100mm Dia. Slewing Ring Bearing - 5,620 lbs Max Axial Static
