OEM#: PRT-01-60New OEM Original Outright
160MM DIA. SLEWING RING BEARING - 11,240 LBS MAX AXIAL STATIC by igus
Your price:
$412.34 each
OEM#: PRT-01-60160MM DIA. SLEWING RING BEARING - 11,240 LBS MAX AXIAL STATIC by igus
New OEM Original Outright
Your price:
$412.34 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
160mm Dia. Slewing Ring Bearing - 11,240 lbs Max Axial Static
iglide® PRT is a slewing ring bearing with the proven advantage of igus® plastic bearings. The iglide® J sliding elements are completely maintenance-free and lubrication-free. All the housing components are made of aluminum (except style 02, which has iglide® J4 head rings), and all the parallel surfaces of iglide® J sliding elements are hard anodized. All the fixing screws are made of stainless steel. The PRT slewing rings are available on request in stainless steel.
iglide® PRT is a slewing ring bearing with the proven advantage of igus® plastic bearings. The iglide® J sliding elements are completely maintenance-free and lubrication-free. All the housing components are made of aluminum (except style 02, which has iglide® J4 head rings), and all the parallel surfaces of iglide® J sliding elements are hard anodized. All the fixing screws are made of stainless steel. The PRT slewing rings are available on request in stainless steel.
Technical Specs
P/N: PRT-01-60 Key Specs
Item
160MM DIA. SLEWING RING BEARING - 11,240 LBS MAX AXIAL STATIC
OEM
igus
OEM #
PRT-01-60
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Color
Metal/Yellow
Dimension A
28
Dimension B
4.5
Dimension D
160mm
Dimension D1
74
Dimension D2
130
Dimension H
10
Dimension R1
65
Dimension R2
51.5
Dimension S1
M5
Dimension S2
5.5
Dimension T1
10 x 36°
Dimension T2
20 x 18°
K1 Screw (Din912)
DIN 912 M5
Manufacturer Name
igus, Inc.
Max Axial Dynamic
3,372 lbs.
Max Axial Static
11,240 lbs.
Max Radial Dynamic
674 lbs.
Max Radial Static
2,248 lbs.
160mm Dia. Slewing Ring Bearing - 11,240 lbs Max Axial Static
iglide® PRT is a slewing ring bearing with the proven advantage of igus® plastic bearings. The iglide® J sliding elements are completely maintenance-free and lubrication-free. All the housing components are made of aluminum (except style 02, which has iglide® J4 head rings), and all the parallel surfaces of iglide® J sliding elements are hard anodized. All the fixing screws are made of stainless steel. The PRT slewing rings are available on request in stainless steel.
iglide® PRT is a slewing ring bearing with the proven advantage of igus® plastic bearings. The iglide® J sliding elements are completely maintenance-free and lubrication-free. All the housing components are made of aluminum (except style 02, which has iglide® J4 head rings), and all the parallel surfaces of iglide® J sliding elements are hard anodized. All the fixing screws are made of stainless steel. The PRT slewing rings are available on request in stainless steel.
