OEM#: OJUI-11-20New OEM Original Outright
DRYLIN R OPEN PILLOW BLOCK POLYMER BEARING WITH SHELL - 1-1/4" DIA. SHAFT by igus
Your price:
$169.95 each
OEM#: OJUI-11-20DRYLIN R OPEN PILLOW BLOCK POLYMER BEARING WITH SHELL - 1-1/4" DIA. SHAFT by igus
New OEM Original Outright
Your price:
$169.95 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
DryLin R Open Pillow Block Polymer Bearing with shell - 1-1/4" Dia. Shaft
Special Properties:
- Open, anodized aluminum housing
- Liner JUI-01 made from iglide® J contained according to standard tolerances
- Can be fitted with T500 liner material for temperatures up to 356°F
- Low clearance liners optional
Technical Specs
P/N: OJUI-11-20 Key Specs
Item
DRYLIN R OPEN PILLOW BLOCK POLYMER BEARING WITH SHELL - 1-1/4" DIA. SHAFT
OEM
igus
OEM #
OJUI-11-20
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Dimension A
1.5
Dimension B
4
Dimension C
2.875
Dimension E
3.5
Dimension F
2
Dimension G
3
Dimension J
0.438
Dimension K
3.625
Dimension M
2.625
Dimension O
0.068
Dimension P
2.122
Dimension R
0.625
H Bolt/Hole
#10 7/32
Manufacturer Name
igus, Inc.
Nominal Size Inches
2
Static Load Lbs. @ 0°
8287
Static Load Lbs. @ 180°
2912
Static Load Lbs. @ 90°
5659
Temperature (°F)
-40 to 194
