OEM#: GF15WNew OEM Original Outright

GFCI RECEPTACLE, DUPLEX, WHITE, 5-15R, 15 A, 125V AC, 2 POLE / 3 WIRE, GEN USE by Hubbell Power Systems

Your price:
$43.05 eachReady to ship
HomeHubbell Power Systemsgf15w
GFCI RECEPTACLE, DUPLEX, WHITE, 5-15R, 15 A, 125V AC, 2 POLE / 3 WIRE, GEN USE by Hubbell Power Systems
GFCI RECEPTACLE, DUPLEX, WHITE, 5-15R, 15 A, 125V AC, 2 POLE / 3 WIRE, GEN USE by Hubbell Power Systems

OEM#: GF15W
GFCI RECEPTACLE, DUPLEX, WHITE, 5-15R, 15 A, 125V AC, 2 POLE / 3 WIRE, GEN USE by Hubbell Power Systems

New OEM Original Outright
Your price:
$43.05 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: GF15W Key Specs
Item
GFCI RECEPTACLE, DUPLEX, WHITE, 5-15R, 15 A, 125V AC, 2 POLE / 3 WIRE, GEN USE
OEM
Hubbell Power Systems
OEM #
GF15W
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
AFCI
No
Connection Orientation
Straight
Contact Material
Brass
Country of Origin
China
Cover Type
No Cover
Current Rating
15 A
Face Plate Width
1.8 in
GFCI
Yes
Grade
General Use
Grounding
Grounded
Horsepower Rating
1/2 hp
Housing Color
White
Housing Material
Thermoplastic
Includes
Mounting Hardware
Includes Mounting Hardware
Yes
Maximum Operating Temperature
150 °F
Maximum Wire Size
10 AWG
Minimum Operating Temperature
-30 °F
Minimum Wire Size
14 AWG
Mount Hole Center-to-Center Height
3.3 in
Mount Type
Flush
NEMA Receptacle Configuration
5-15R
Number of Gangs
1
Number of Poles
2
Number of Wires
3
Overall Depth
1.5 in
Phase
Single
Polarized
Yes
Receptacle Type
Duplex
Reset Type
Automatic
Self Testing
Yes
Standards
ADA; CSA Certified; cULus; NEC; NEMA WD-6
Sub-brand
Bryant
Surge Protection
No
UL 94 Flammability Rating
V-2
Voltage Rating
125V AC
Wire Connection Location
Back; Side
Wire Connection Type
Screw Terminals
Wire Connection Types
Screw Terminals
