OEM#: DRS15WTRNew OEM Original Outright
RECEPTACLE, DECORATOR DUPLEX, WHITE, 5-15R, 15 A, 125V AC, 2 POLE / 3 WIRE by Hubbell Power Systems
Your price:
$11.40 each
OEM#: DRS15WTRRECEPTACLE, DECORATOR DUPLEX, WHITE, 5-15R, 15 A, 125V AC, 2 POLE / 3 WIRE by Hubbell Power Systems
New OEM Original Outright
Your price:
$11.40 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: DRS15WTR Key Specs
Item
RECEPTACLE, DECORATOR DUPLEX, WHITE, 5-15R, 15 A, 125V AC, 2 POLE / 3 WIRE
OEM
Hubbell Power Systems
OEM #
DRS15WTR
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
AFCI
No
Approvals, Certifications & Standards
CSA Certified; Federal Specification; UL Listed
Connection Orientation
Straight
Country of Origin
China
Cover Type
No Cover
Current Rating
15 A
GFCI
No
Grade
Federal Specification
Grounding
Grounded
Horsepower Rating
1/2 hp
Housing Color
White
Housing Material
Composite
Includes
Mounting Hardware
Includes Mounting Hardware
Yes
Maximum Wire Size
12 AWG
Minimum Wire Size
14 AWG
Mount Type
Flush
NEMA Receptacle Configuration
5-15R
Number of Gangs
1
Number of Poles
2
Number of Wires
3
Phase
Single
Polarized
Yes
Receptacle Type
Decorator Duplex
Special Resistance
Tamper Resistant
Surge Protection
No
Voltage Rating
125V AC
Wire Connection Location
Back; Side
Wire Connection Type
Screw Terminals
Wire Connection Types
Screw Terminals
