OEM#: BRY4100C7WNew OEM Original Outright

WATERTIGHT PIN AND SLEEVE CONNECTOR, 100 A, 480V AC, 30 HP HORSEPOWER RATING, IEC GROUNDING, IEC 309 by Hubbell Power Systems

Your price:
$642.02 eachReady to ship
HomeHubbell Power Systems4100C7W
WATERTIGHT PIN AND SLEEVE CONNECTOR, 100 A, 480V AC, 30 HP HORSEPOWER RATING, IEC GROUNDING, IEC 309 by Hubbell Power Systems
WATERTIGHT PIN AND SLEEVE CONNECTOR, 100 A, 480V AC, 30 HP HORSEPOWER RATING, IEC GROUNDING, IEC 309 by Hubbell Power Systems

OEM#: BRY4100C7W
WATERTIGHT PIN AND SLEEVE CONNECTOR, 100 A, 480V AC, 30 HP HORSEPOWER RATING, IEC GROUNDING, IEC 309 by Hubbell Power Systems

New OEM Original Outright
Your price:
$642.02 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: BRY4100C7W Key Specs
Item
WATERTIGHT PIN AND SLEEVE CONNECTOR, 100 A, 480V AC, 30 HP HORSEPOWER RATING, IEC GROUNDING, IEC 309
OEM
Hubbell Power Systems
OEM #
BRY4100C7W
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Cap Type
Spring-Loaded Cap
Connection Orientation
Straight
Country of Origin
Germany
Current Rating
100 A
Features
Sleet Resistant
For Maximum Cable Diameter
1.94 in
For Minimum Cable Diameter
0.9 in
Grounding
Grounded
Grounding Style
IEC
Hazardous Location Specification
Not Rated
Horsepower Rating
30 hp
Housing Color
Red
Housing Material
Composite
IP Rating
IP67
Market
Industrial
Maximum Operating Temperature
75 °C
Maximum Wire Size
1/0 AWG
Minimum Operating Temperature
-40 °C
Minimum Wire Size
3 AWG
NEMA Enclosure Rating
Not Rated
Number of Poles
3
Number of Wires
4
Overall Length
13.57 in
Phase
Three
Power Indicating Light
No
Resistance Properties
Watertight
Reverse Service
No
Shrouded
Yes
Standards
IEC 309-1; IEC 309-2; UL 498
Switch Rated
No
UL 94 Flammability Rating
Not Rated
Voltage Rating
480V AC
Wire Connection Type
Screw Terminals
