OEM#: MS8120A1007New OEM Original Outright

ELECTRIC ACTUATOR 24VAC/DC SPST by Honeywell

Your price:
$458.82 eachReady to ship
HomeHoneywellMS8120A1007
ELECTRIC ACTUATOR 24VAC/DC SPST by Honeywell
ELECTRIC ACTUATOR 24VAC/DC SPST by Honeywell

OEM#: MS8120A1007
ELECTRIC ACTUATOR 24VAC/DC SPST by Honeywell

New OEM Original Outright
Your price:
$458.82 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: MS8120A1007 Key Specs
Item
ELECTRIC ACTUATOR 24VAC/DC SPST
OEM
Honeywell
OEM #
MS8120A1007
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temperature Range
-40 Degrees to 140 Degrees F
Depth
2-15/16 in
Electrical Connections
Enclosed Screw Terminal Strip
For Use With
Valves and Dampers
Height
9-3/4 in
Includes
3mm Crank, Mounting Bracket, Self-Centering Shaft Adapter
Motor Direction
CW or CCW
Mounting Type
Direct Mount
Power Consumption
40VA Driving, 8VA Holding
Shaft Type
Self-Centering Clamping
Spring Return
Yes
Stroke Degrees
95 +/-3
Switch Type
SPST
Timing
20 sec Spring Return, 45 sec Nominal @ 60 Hz
Torque
175 in-lb
Voltage
24V AC/DC
Width
3-15/16 in
