OEM#: 96402730New OEM Original Outright

VERSAFLO UPS32-160 CIRCULATOR PUMP, CAST IRON, 115V, 3/4 HP by Grundfos

Your price:
$2,562.00 eachReady to ship
HomeGrundfos96402730
VERSAFLO UPS32-160 CIRCULATOR PUMP, CAST IRON, 115V, 3/4 HP by Grundfos
VERSAFLO UPS32-160 CIRCULATOR PUMP, CAST IRON, 115V, 3/4 HP by Grundfos

OEM#: 96402730
VERSAFLO UPS32-160 CIRCULATOR PUMP, CAST IRON, 115V, 3/4 HP by Grundfos

New OEM Original Outright
Your price:
$2,562.00 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 96402730 Key Specs
Item
VERSAFLO UPS32-160 CIRCULATOR PUMP, CAST IRON, 115V, 3/4 HP
OEM
Grundfos
OEM #
96402730
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Capacitor Size - Run
60 µF/250 V
Color
Red
Flange Standard
USA Oval
Flow U.S. Gpm
9-76
Head Feet
1-45
Height Inches
13-1/2
Horsepower
3/4
Housing Material
Cast Iron
Impeller Material
Stainless Steel
Istart Amps
14.6
Length Inches
6
Max. Amps
5.8
Max. Watts
625
Maximum Ambient Temperature °F
104 °F
Maximum Fluid Temperature °F
248°F
Maximum Rpm
3450
Minimum Fluid Temperature °F
14°
Model
UPS32-160
Motor Protection
Contact
Number Of Poles
2
Number Of Speeds
3
Phase
1
Pipe Connection
32
Port To Port Length Inches
13-1/2
Pos Term Box
1.30H
Pressure Psi
145
Thermal Protection
Internal
Voltage
5.8
Weight Lbs
36.96
Width Inches
12-1/4
