OEM#: 6107ENew OEM Original Outright
ELECTRIC MOTOR ECM OPEN AIR-OVER 3/4 HP by Genteq
Your price:
$454.28 each $634.85 Savings: $180.57 (28%)
OEM#: 6107EELECTRIC MOTOR ECM OPEN AIR-OVER 3/4 HP by Genteq
New OEM Original Outright
Your price:
$454.28 each
$634.85 Savings: $180.57 (28%)
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 6107E Key Specs
Item
ELECTRIC MOTOR ECM OPEN AIR-OVER 3/4 HP
OEM
Genteq
OEM #
6107E
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temperature
-20 Degrees to 45 Degrees C
Application
Direct Drive Blower
Body Diameter
5-3/4 in
Capacitor Required
No
Duty
Continuous
Frame
48
Full Load Amps
8.4
HP
3/4 hp
Hz
60/50
Includes
Wiring Harness
Ins. Class
B
Length Less Shaft
6-1/2 in
Max Ambient Temperature
40 Degrees C
Motor Application
HVAC/R
Motor Bearings
Ball
Motor Design
ECM
Motor Enclosure Design
Open Air-Over
Motor Frame Material
Rolled Steel
Motor Mounting Position
All Angle
Motor Mounting Type
Band
Motor Service Factor
1
Motor Shaft Design
Flat
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Direct Drive Fan/Blower
Motor Thermal Protection
None
Nameplate RPM
1200
Number of Speeds
5
Overall Length
11-1/2 in
Phase
1
Plug Type
Wiring Harness
Shaft Diameter
1/2 in
Shaft Length
4-15/16 in
Standards
CSA Certified (MC236833), E27885, E306343), UL Recognized (E46035
Voltage
115
