OEM#: 6010New OEM Original Outright
BRUSHLESS DIRECT DRIVE BLOWER ECM 1 HP by Genteq
Your price:
$406.42 each $653.58 Savings: $247.16 (38%)
OEM#: 6010BRUSHLESS DIRECT DRIVE BLOWER ECM 1 HP by Genteq
New OEM Original Outright
Your price:
$406.42 each
$653.58 Savings: $247.16 (38%)
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 6010 Key Specs
Item
BRUSHLESS DIRECT DRIVE BLOWER ECM 1 HP
OEM
Genteq
OEM #
6010
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temperature
-40 to 40 Degrees C
Application
HP PSC Motors in Residential, Light Commercial HVAC Systems
Body Diameter
5-5/8 in
Capacitor Required
No
Duty
Continuous
Frame
48
Full Load Amps
11/6.7
HP
1
Hz
60/50
Includes
115VAC White Jumper and HVAC System ID Label
Ins. Class
B
Max Ambient Temperature
40 Degrees C
Motor Application
HVAC/R
Motor Bearings
Ball
Motor Design
ECM
Motor Enclosure Design
Open Air-Over
Motor Frame Material
Cast Aluminum
Motor Mounting Position
All Angle
Motor Mounting Type
Band
Motor Service Factor
1
Motor Shaft Design
Flat
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Direct Drive Fan/Blower
Motor Thermal Protection
Auto
Nameplate RPM
1070
Number of Speeds
1
Overall Length
12-3/4 in
Phase
1
RPM Range
1001-1100
Shaft Diameter
1/2 in
Shaft Length
4-15/16 in
Standards
UL Recognized (1004)
Voltage
115/230
Voltage Compatibility
115, 115/230, 120, 120/240, 230, 240
