SOLAR 8000M POWER SUPPLY PRINTED CIRCUIT BOARD by GE Medical Systems Information Technology (GEMSIT)
OEM#: 801674-001SOLAR 8000M POWER SUPPLY PRINTED CIRCUIT BOARD by GE Medical Systems Information Technology (GEMSIT)
Drop Shipped From GE - Not For Export Out Of US
This Solar 8000M power supply includes a mains (AC line) PWM converter, that comes from a 16.75 output voltage bus from which two outputs are developed. This board is designed with an EMI Input Filter, Over Voltage and Current protections along with a current feedback control loop. It comes with an IEC320 input connector with built-in switch which is safeguarded using a fuse. Outputs for a Fan, mains and thin client are provided using appropriate connectors. Material for the board is made of FR-4 that consists of glass fabric, and electrical grade epoxy resin. The power supply is used with Solar 8000M Patient Monitoring Ultrasound systems.
Additional Features:
- Pulse Width Modulation (PWM) Technology
- On Board 3 Output Connectors
- IEC320 Input Connector
- Compact Size
This Solar 8000M power supply includes a mains (AC line) PWM converter, that comes from a 16.75 output voltage bus from which two outputs are developed. This board is designed with an EMI Input Filter, Over Voltage and Current protections along with a current feedback control loop. It comes with an IEC320 input connector with built-in switch which is safeguarded using a fuse. Outputs for a Fan, mains and thin client are provided using appropriate connectors. Material for the board is made of FR-4 that consists of glass fabric, and electrical grade epoxy resin. The power supply is used with Solar 8000M Patient Monitoring Ultrasound systems.
