Replaces GE Healthcare GA200039

Z-MECHANISM ASSY

The z mechanism is used in an ultrasound system, it is equipped with a release handle that can be operated in order to move the top console up or down without connecting power to the vivid e90 ultrasound system. This method repeats when the drive gear is disconnected or has failed, or if the main power is turned off, disconnected or has a power failure. The top console can drop unexpectedly when the mechanism is released. Move the handle a few millimeters to the right side, to release the z mechanism, and at the same time move the top console up or down, as required. There are no adjustments for the operating panel’s vertical movement. The vertical movement of the top console is motor driven. The control buttons for the electrical motor are located around the handles. A gas spring inside the ultrasound system assists in the z-axis (vertical) movement.

• Easy to Install and dismantle
• RoHS compliant

The z mechanism is used in an ultrasound system, it is equipped with a release handle that can be operated in order to move the top console up or down without connecting power to the vivid e90 ultrasound system. This method repeats when the drive gear is disconnected or has failed, or if the main power is turned off, disconnected or has a power failure. The top console can drop unexpectedly when the mechanism is released. Move the handle a few millimeters to the right side, to release the z mechanism, and at the same time move the top console up or down, as required. There are no adjustments for the operating panel’s vertical movement. The vertical movement of the top console is motor driven. The control buttons for the electrical motor are located around the handles. A gas spring inside the ultrasound system assists in the z-axis (vertical) movement.

• GE Healthcare
  • LOGIQ E9
  • VIVID E9
  • LOGIQ 9
  • VIVID E9
