Replaces GE Healthcare 5341631

OPTICAL TRACKBALL - NOT REMOVABLE

The Optical Trackball TG3 is used mainly in ultrasound and other Digital Imaging (DI) healthcare devices. It is mounted in the operator panel of the machine. It communicates with the ultrasound’s host computer over USB through a HUB built into the operator panel electronics. Over USB, the trackball position data and the status of the mouse buttons shall be communicated via a standard Microsoft driver. The trackball unit is supplied along with a ribbon cable. The cable is necessary as the trackball replaces a previous design that had an integral cable for connecting to the mouse buttons. Both the trackball and the cable are safely packed with adequate protection to survive the drop test. As this works on the optical sensor, the integrated circuit with optics take continual snapshot of ball surface and how the features in these snapshots move is used to detect ball motion. This product is used specifically in machines like LOGIQ E9, LightSpeed 7.X VCT 64-Slice, Vivid E9, Discovery MR750w GEM 3.0T, LOGIQ P5 PREMIUM, Voluson E8, Precision 500D, INNOVA IGS 530, Signa Horizon LX 1.5T, Signa HDxt 1.5T, ABUS Invenia GEN II and Optima XR220amx among others. They come with a smooth finish without any burrs, sharp edges, surface blemishes, sink marks and flash marks.

Additional Features

• It operates with good linearity
• The optical sensor allows picking at 1 pixel resolution
• At rest, it wont show any motion
• It handles high speed motion
• Increased lifespan
• Low environmental impact
• Easy to install
• Enhanced durability
• Easily portable
• Lightweight
• Easy to clean
• RoHS compliant

• Seller: PartsSource
• Condition: Tested
• Purchase Type: Exchange
• Warranty: 6 Month
• Returnable: No

• 5207000-5: GE Healthcare

• GE Healthcare
  • LOGIQ E9
  • VIVID E9

The Optical Trackball TG3 is used mainly in ultrasound and other Digital Imaging (DI) healthcare devices. It is mounted in the operator panel of the machine. It communicates with the ultrasound’s host computer over USB through a HUB built into the operator panel electronics. Over USB, the trackball position data and the status of the mouse buttons shall be communicated via a standard Microsoft driver. The trackball unit is supplied along with a ribbon cable. The cable is necessary as the trackball replaces a previous design that had an integral cable for connecting to the mouse buttons. Both the trackball and the cable are safely packed with adequate protection to survive the drop test. As this works on the optical sensor, the integrated circuit with optics take continual snapshot of ball surface and how the features in these snapshots move is used to detect ball motion. This product is used specifically in machines like LOGIQ E9, LightSpeed 7.X VCT 64-Slice, Vivid E9, Discovery MR750w GEM 3.0T, LOGIQ P5 PREMIUM, Voluson E8, Precision 500D, INNOVA IGS 530, Signa Horizon LX 1.5T, Signa HDxt 1.5T, ABUS Invenia GEN II and Optima XR220amx among others. They come with a smooth finish without any burrs, sharp edges, surface blemishes, sink marks and flash marks.
