LAMBDA MAIN POWER SUPPLY FOR GE ULTRASOUND

The Main Power Supply is specially designed DC regulated voltage intended for use in GE ultrasound system. The Main Power Supply’s main task is to galvanically isolate the scanner from the on-site Mains Power System and to supply the various internal subsystems with AC or DC power. It is an AC/DC converter generating all main DC voltages at or above 6V. The power supply includes all AC components such as the mains input connector, fuses, filters, and inrush current limiter. The main power supply also has an inverter for 110V output (isolated side). This power supply operates at 90 to 250 VAC input voltage and offers DC output required by the system. It comes in a rectangular shape sheet metal chassis with one corner remove for BEP (Back End Processor) fan and external connection access. This power supply is compatible with consoles running R4 or later. This RoHS compliant power supply with CW improvements can be used with GE's Logiq E9 Ultrasound Systems.
