3.0T 16 CHANNEL SWITCH ASSEMBLY by GE Healthcare
OEM#: 5109645-23.0T 16 CHANNEL SWITCH ASSEMBLY by GE Healthcare
Drop Shipped From GE - Not For Export Out Of US
This 16 Channel Switch switches 4 RF Coil Interface connectors (32 independent channels) to 16 receivers. The assembly consists of a 16 channel switch circuit board, mechanical enclosure, label and mounting hardwares including screws and washers. The circuit board consists of capacitors, resistors, serial EEPROM memory, IC's, Mosfet, LEDs, Diodes, inductors, voltage regators, oscillators, FPGA, PLDs, image rejet filter, trimmers and connectors. The 3.0T 16 Channel Switch interfaces with MR coils (antennas) from the coil interface connectors through a Gain Stage to 16 channel RF receivers. The circuit board is made up of FR-4 Glass fiber, a composite material made of glass fabric,and epoxy resin.
- Field Replaceable Unit (FRU)
- Electrically conductive and non-corrosive exterior finish
- Low maintenance required
- High performance
- Reliable and durable
- Does not interfere with other subsystems
- Field Replaceable Unit (FRU)
- Electrically conductive and non-corrosive exterior finish
- Low maintenance required
- High performance
- Reliable and durable
- Does not interfere with other subsystems
This 16 Channel Switch switches 4 RF Coil Interface connectors (32 independent channels) to 16 receivers. The assembly consists of a 16 channel switch circuit board, mechanical enclosure, label and mounting hardwares including screws and washers. The circuit board consists of capacitors, resistors, serial EEPROM memory, IC's, Mosfet, LEDs, Diodes, inductors, voltage regators, oscillators, FPGA, PLDs, image rejet filter, trimmers and connectors. The 3.0T 16 Channel Switch interfaces with MR coils (antennas) from the coil interface connectors through a Gain Stage to 16 channel RF receivers. The circuit board is made up of FR-4 Glass fiber, a composite material made of glass fabric,and epoxy resin.
- Field Replaceable Unit (FRU)
- Electrically conductive and non-corrosive exterior finish
- Low maintenance required
- High performance
- Reliable and durable
- Does not interfere with other subsystems
- GE Healthcare
- SIGNA HDXT 3.0T
- SIGNA HDX 3.0T
- SIGNA EXCITE 3.0T
