OEM#: FS-P2603DNew OEM Original Outright

26 IN MEDICAL MONITOR, DUAL INPUT TFT LCD WITH IPS TECHNOLOGY by Foreseeson Custom Displays/OPHIT/FSN Medical

Your price:
$6,514.44 eachReady to ship
26 IN MEDICAL MONITOR, DUAL INPUT TFT LCD WITH IPS TECHNOLOGY by Foreseeson Custom Displays/OPHIT/FSN Medical
26 IN MEDICAL MONITOR, DUAL INPUT TFT LCD WITH IPS TECHNOLOGY by Foreseeson Custom Displays/OPHIT/FSN Medical

OEM#: FS-P2603D
26 IN MEDICAL MONITOR, DUAL INPUT TFT LCD WITH IPS TECHNOLOGY by Foreseeson Custom Displays/OPHIT/FSN Medical

New OEM Original Outright
Your price:
$6,514.44 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
Product Overview

Products are engineered and built for compatibility with other highly specialized surgical and diagnostic equipment used in surgical suites, operating rooms, emergency rooms, and procedural facilities. The 26" medical display, is uniquely equipped to handle tasks in the demanding OR environment.

It is a pioneer and world leader in medical video signal management, distribution, and display. From concept, design, prototype, certification, and production, to interface design, all FSN products are characterized by their seamless usability, compact modularity and robust design.

  • Dual DVI inputs and outputs
  • Rapid signal detection, robust mode tables
  • Artifact-free HD images
  • Fanless - sterile field compatible
  • Calibrated to clinical color
  • Image pan, zoom, freeze, picture-in-picture
Features
  • Compatible with new or existing surgical integration applications
  • Full-featured image control, precise surgical site visualization
  • Allows mounting on spring arms and surgical booms
  • Medical-grade construction, surgical environment ready
  • Certified for near-patient use in the sterile field
Technical Specs
P/N: FS-P2603D Key Specs
Item
26 IN MEDICAL MONITOR, DUAL INPUT TFT LCD WITH IPS TECHNOLOGY
OEM
Foreseeson Custom Displays/OPHIT/FSN Medical
OEM #
FS-P2603D
Condition
New OEM Original
Returnable
Yes
Warranty
12 Month
Active Area
576 mm H x 324 mm V
Aspect Ratio
16 : 9
Brightness
450 cd/m2
Contrast Ratio
1900-03-02
Dimensions
26.3 in W x 16.57 in H X 3.5 in D
IP Rating
IP32; IP44
Input Signal
2 x DVI-D 2 x SD/HD/3G-SDI (BNC) 2 x SOG 1 x VGA (D-sub) 1 x C-Video (BNC) 1 x S-Video (DIN) 1 x Component (RGBS; YPbPr) (5 x BNC)
Maximum Luminance
500 CD/M²
Number of Colors
1.07 Billion
Output Signal
2 x DVI-D; 2 x SD/HD/3G-SDI (BNC); 2 x SOG; 1 x C-Video (BNC); 1 x S-Video (DIN); 1 x Component (RGBS; YPbPr) (5 x BNC)
Package Dimensions
29.75 in W x 25.75 in H x 9.25 in D
Package Weight
28.33 lb
Pixel Pitch
0.3 x 0.3
Power Consumption
70 W max
Power Supply
100 to 240 V
Resolution
1920 x 1080 Pixel
Response Time
8 MS
Screen Size
26 IN
Screen Type
TFT LCD
Standards and Approvals
ANSI/AAMI ES60601-1(UL60601-1); CAN/CSA C22.2 No. 60601-1; FCC Class B; EN60601-1; EN60601-1-2; CE; MDR(EU) 2017/745 Class I Medical Device
Surface Treatment
Anti-glare
Technology
IPS
Video Input Connectors
1 x DVI?D 1 1 x DVI?D 2 (Optional, Fiber DVI Receiver DDL?Rx, DSP?Rx, DSL?Rx Detachable) 1 x D?SUB 1 x BNC (SD/HD/3G?SDI) 1 x BNC (CVBS) 2 x BNC (SVHS Y/C) 5 x BNC (Component Y/G, Pb/B, Pr/R, H/CS,VS Input)
Viewing Angle
R/L 178, U/D 178
Weight
19.03 lb
