OEM#: 2811919New OEM Original Outright

DEFIBRILLATOR ANALYZER AND PACEMAKER TESTER by Fluke Electronics Corp (Biomedical Div.)

Your price:
$10,970.52 eachReady to ship
HomeFluke Electronics Corp (Biomedical Div.)2811919
DEFIBRILLATOR ANALYZER AND PACEMAKER TESTER by Fluke Electronics Corp (Biomedical Div.)
DEFIBRILLATOR ANALYZER AND PACEMAKER TESTER by Fluke Electronics Corp (Biomedical Div.)
DEFIBRILLATOR ANALYZER AND PACEMAKER TESTER by Fluke Electronics Corp (Biomedical Div.)
DEFIBRILLATOR ANALYZER AND PACEMAKER TESTER by Fluke Electronics Corp (Biomedical Div.)
View All

OEM#: 2811919
DEFIBRILLATOR ANALYZER AND PACEMAKER TESTER by Fluke Electronics Corp (Biomedical Div.)

New OEM Original Outright
Your price:
$10,970.52 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview

Test defibs, AEDs and external pacers. Fluke Biomedical’s defibrillator analyzers and defibrillator/transcutaneous pacemaker testing devices are rugged, portable precision test instruments that ensure proper operation and ultimate performance of critical life-support cardiac-resuscitation equipment. We offer best-in-class defibrillator testers that feature capabilities which encompass a wide spectrum of worldwide established pulse shapes, showcasing AED tester compatibility, and outperforming competitors in accuracy and standards.

The Impulse 7000DP defibrillator AED analyzer ensures proper operation and ultimate performance of critical life-support cardiac-resuscitation equipment, including mono- and bi-phasic defibrillators and AEDs. This best-in-class defibrillator analyzer offers test capabilities that encompass a global spectrum of established pulse shapes, feature breakthrough AED technology compatibility, and deliver superior performance with accuracy readings +/- 1% of reading +0.1J.

Features
  • Flexible heart-rate settings (1 BPM step) facilitate rate meter accuracy and alarm testing
  • Impulse 7010 Defibrillator Selectable Load Accessory provides multiple loads of 25 Ω, 50 Ω, 75 Ω,100 Ω, 125 Ω, 150 Ω, 175 Ω, and 200 Ω to comply with IEC 60601-2-4 standard (optional)
  • Lown, Edmark, trapezoidal, biphasic and pulsed-biphasic defibrillation technology compatibility
  • AED technology compatibility
  • First-class measurement accuracy ± 1 % of reading + 0.1 J
  • Intuitive user interface and backlight, easy-to-read display
  • Portable, rugged, easy to carry
  • Long-lasting, rechargeable battery
  • Pacer input protected against defibrillator output
  • 10 independent ECG outputs that provide 12 lead combinations for standardized clinical signals
Technical Specs
P/N: 2811919 Key Specs
Item
DEFIBRILLATOR ANALYZER AND PACEMAKER TESTER
OEM
Fluke Electronics Corp (Biomedical Div.)
OEM #
2811919
Condition
New OEM Original
Returnable
No
Warranty
12 Month
Accuracy
± 1 ms
Amplitude
1 mV
Battery Charger
100 V to 240 V input; 15 V/1.5 V A output. For best performance, the battery charger should be connected to a properly grounded ac receptacle
Communications
USB device port for computer control
Current
2 to 250 mA; ± (1% of reading + 0.02 mA)
Dimensions
32 cm x 24 cm x 13 cm (13 in x 9.5 in x 5 in)
Display
LCD display
ECG Amplitude
1 mV
ECG Pulse Width
40 ms
ECG Waveform
Triangle wave
Enclosure
ABS plastic housing
Humidity
10 % to 90 % non-condensing
Input pacer pulse rates
30 to 200 PPM
Modes of Operation
Manual and remote
Operating Temperature
10 deg C to 40 deg C (50 deg F to 104 deg F)
Operating voltage range
100 to 240 V AC
Overdrive rate
300 BPM maximum
Paced Refractory Period
20 to 500 ms
Pacer pulse rate
20 to 200 PPM
Power
Internal rechargeable NiMH battery pack for nine hours (typical) operation after full charge or the battery charger can operate the analyzer and charge the battery simultaneously
Pulse rate
5 to 800 PPM; ± (0.5% of reading + 0.1 PPM)
Pulse width
1 to 100 ms; ± (0.5% of reading + 0.01 ms)
Rate
10 to 300 BPM in 1 BPM increments
Safety Standards
CE: IEC/EN61010-1 2nd Edition; Pollution degree 2 CAN/CSA-C22.2 No. 61010-1; UL61010-1 C-Tick: Australian EMC
Sensed Refractory Period
15 to 500 ms
Storage Temperature
-20 deg C to +60 deg C (-4 deg F to +140 deg F)
Underdrive rate
10 BPM minimum
Volts
120 V
Weight
3.02 kg (6.6 lb; 0.1 oz)
Fitments

Test defibs, AEDs and external pacers. Fluke Biomedical’s defibrillator analyzers and defibrillator/transcutaneous pacemaker testing devices are rugged, portable precision test instruments that ensure proper operation and ultimate performance of critical life-support cardiac-resuscitation equipment. We offer best-in-class defibrillator testers that feature capabilities which encompass a wide spectrum of worldwide established pulse shapes, showcasing AED tester compatibility, and outperforming competitors in accuracy and standards.

The Impulse 7000DP defibrillator AED analyzer ensures proper operation and ultimate performance of critical life-support cardiac-resuscitation equipment, including mono- and bi-phasic defibrillators and AEDs. This best-in-class defibrillator analyzer offers test capabilities that encompass a global spectrum of established pulse shapes, feature breakthrough AED technology compatibility, and deliver superior performance with accuracy readings +/- 1% of reading +0.1J.

    • Fluke Electronics Corp (Biomedical Div.)
      • IMPULSE 7000DP
