OEM#: PB270-2New OEM Original Outright
STEEL 11 D 13.9 H 7.3 W INLINE DUCT FAN by Fantech
Your price:
$352.53 each
OEM#: PB270-2STEEL 11 D 13.9 H 7.3 W INLINE DUCT FAN by Fantech
New OEM Original Outright
Your price:
$352.53 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: PB270-2 Key Specs
Item
STEEL 11 D 13.9 H 7.3 W INLINE DUCT FAN
OEM
Fantech
OEM #
PB270-2
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Approvals, Certifications & Standards
HVI, cULus, UL Listed for Wet Locations
Bearing Type
Ball
CFM @ 0.000 in SP
303
CFM @ 0.200 in SP
260
CFM @ 0.400 in SP
229
CFM @ 0.600 in SP
196
CFM @ 0.800 in SP
160
CFM @ 1.000 in SP
134
CFM @ 1.500 in SP
58
CFM @ Duct
270
Fits Duct Diameter
4 in, 6 in
Flange Width
1 in
Green Certification or Other Recognition
ENERGY STAR(R) Certified
Green Environmental Attribute
Product Contributes To Reducing Energy Consumption
Housing Diameter
11 3/8 in
Housing Material
Galvanized Steel
Hz
60
Includes
(1) Centrifugal Fan with Mounting Bracket, (2) Ceiling Grilles, (2) Grille Housings with Dampers, Y Adapter
Inlet & Outlet Diameter
6 in
Length
8 in
Maximum Amps
0.68 A
Maximum Inlet Temperature
140 Degrees F
Maximum Wattage
72
Motor Enclosure
Totally Enclosed
Motor Horsepower
1/10 hp
Motor RPM
2700
Mounting Position
Horizontal or Vertical
Number of Speeds
1
Phase
1
Speed Control
Mfr. No. 48C172
Voltage
120V
