OEM#: STV25K24SNew OEM Original Outright
SURGE PROTECTION DEVICE 240VAC 1PH by Emerson Industrial
Your price:
$719.13 each
OEM#: STV25K24SSURGE PROTECTION DEVICE 240VAC 1PH by Emerson Industrial
New OEM Original Outright
Your price:
$719.13 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: STV25K24S Key Specs
Item
SURGE PROTECTION DEVICE 240VAC 1PH
OEM
Emerson Industrial
OEM #
STV25K24S
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Amps
20 A
Approvals, Certifications & Standards
RoHS, Type 4, cULus Listed
Basic Material
Metallic
Country of Origin
Mexico
Depth
4.75 in
Enclosure Material
Metal
Filtering
Yes
IP Rating
20
Includes
LED Status Indicator
Length
4.87 in
Maximum Continuous Operating Voltage
275V AC
Maximum Operating Temperature
140 Degrees F
Maximum Surge Current per Mode
25kA
Maximum Surge Current per Phase
25 kA
Minimum Operating Temperature
-40 Degrees F
Modes of Protection
L-G, L-L, L-N, N-G
Modular
Yes
Mounting Location
Internally Mounted
Mounting Style
DIN Rail
Noise Attenuation
Common 40dB Minimum, Normal: 50dB Minimum
Nominal Discharge Current
3 kA
Number of Poles
3
Number of Wires
2 Wires + Ground
Phase
1
Short Circuit Current Rating
5kA
System Connection
Series
UL SPD Type
Type 4
Voltage
240V AC
Voltage Protection Rating
900V
Width
2.56 in
Wire Gauge
12 AWG
