OEM#: STFE05024LNew OEM Original Outright
SURGE PROTECTION DEVICE 240VAC 1PH by Emerson Industrial
Your price:
$880.34 each
OEM#: STFE05024LSURGE PROTECTION DEVICE 240VAC 1PH by Emerson Industrial
New OEM Original Outright
Your price:
$880.34 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: STFE05024L Key Specs
Item
SURGE PROTECTION DEVICE 240VAC 1PH
OEM
Emerson Industrial
OEM #
STFE05024L
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Amps
5 A
Approvals, Certifications & Standards
CE, RoHS, Type 4, UL Listed, cULus Listed
Basic Material
Metallic
Country of Origin
Mexico
Depth
4.56 in
Enclosure Material
Metal
Filtering
Yes
Green Environmental Attribute
Does not Contain Reproductive or Developmental Toxins (as Per State of CA List), Endocrine Disrupters (as Per European Union Priority For Research List), Asthmagens (as Per AOEC List), Carcinogens (as Per IARC 1-2A-2B Lists)
IP Rating
20
Includes
LED Status Indicator
Length
4.88 in
Maximum Continuous Operating Voltage
275V AC
Maximum Operating Temperature
122 Degrees F
Maximum Surge Current per Mode
10kA (L-G, 20kA (L-N), N-G)
Maximum Surge Current per Phase
30 kA
Minimum Operating Temperature
-40 Degrees F
Modes of Protection
L-G, L-L, L-N, N-G
Modular
Yes
Mounting Location
Internally Mounted
Mounting Style
DIN Rail
Noise Attenuation
Common: 60dB @ 5 MHz to 50 MHz, Normal: 90dB @ 100kHz to 50 MHz
Nominal Discharge Current
5 A
Number of Poles
2
Number of Wires
2 Wires + Ground
Phase
1
Short Circuit Current Rating
5kAIC
System Connection
Series
UL SPD Type
Type 4
Voltage
240V AC
Voltage Protection Rating
1200V (L-G), 800V (L-L)
Width
2.56 in
Wire Gauge
22 AWG
