OEM#: ET1928L-7CWM-1-GY-GNew OEM Original Outright
TOUCHSCREEN MONITOR 19 IN, BLACK by Elo Touch Solutions
Your price:
$994.67 each
OEM#: ET1928L-7CWM-1-GY-GTOUCHSCREEN MONITOR 19 IN, BLACK by Elo Touch Solutions
New OEM Original Outright
Your price:
$994.67 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
The fully featured 1928L touch monitor offers best in class optical performance mated to the leading touch technologies–IntelliTouch surface acoustical wave and AccuTouch five-wire resistive–along with a combination touch controller, DVI, VGA and built-in speakers.
Features
- "Designed for touch" features such as a stable tilt stand, Built in speakers located in the display head
- On Screen Display : Controls (side): menu, up, down, select, power, Settings: contrast , brightness, H-position, V-position, recall default, RGB, volume, sharpness, phase, clock, OSD H-position, OSD V-position, OSD timeout, auto adjust, input select,
- Sealability : Touchscreen sealed to bezel, Touchscreen sealed to LCD
- MTBF : 50,000 hours demonstrated
- 2 stage DPMS, VESA DDC, Plug & Play, Five-second power down delay function, Security lock receptacle
- IPX1 drip-proof enclosure
- Long lasting product cycle-enclosure controlled by Elo specifications
- Touch can be activated with gloved hands
- 5-second power down delay (prevents accidental power shut down)
- Leading edge optical performance
Technical Specs
P/N: ET1928L-7CWM-1-GY-G Key Specs
Item
TOUCHSCREEN MONITOR 19 IN, BLACK
OEM
Elo Touch Solutions
OEM #
ET1928L-7CWM-1-GY-G
Condition
New OEM Original
Returnable
No
Warranty
90 Day
Active Area
14.8 in x 11.9 in
Aspect Ratio
5:4
Brightness
LCD panel: 300 nits; Acoustic Pulse Recognition: 276 nits
Certifications
North America/Worldwide: UL, cUL, CB, MPR II, CE, FCC, VCCI, IC, C-Tick (Class B), Argentina S, IEC, EN61000-4-3; Asia: UL, cUL, CB, MPR II, CE, FCC, VCCI, IC, C-Tick (Class B), Argentina S, MIC, eK, CCC, China RoHS, IEC, EN61000-4-3
Color
Black
Contrast Ratio
1300:1
Diagonal Size
19 in
Dimensions
16.9 in x 15.4 in x 8.3 in
Display Type
LCD
Humidity
Operating: 20%-80%; Storage: 10%-90%; noncondensing
Input Connector
DC: Coaxial power jack (2.5 mm pin diameter, 6.3 mm barrel diameter, 9.5 mm barrel length)
Input Frequency
Horizontal: 31.5-80 kHz; Vertical: 56.3-75 Hz
Input Video Format
Analog VGA; DVI-D
Input Video Signal Connector
Mini D-Sub 15-Pin VGA Type; DVI-D connector
Input Voltage
DC: 12.0 V ± 0.60 V
Mounting Options
100 mm VESA mount; Threaded-Through Mounting Holes; Under Stand
Number of Colors
16.7 Billion
Operating Temperature
0 to 40 deg C
Other Supported Resolutions
1280 x 1024 at 60 or 75 Hz; 1280 x 960 at 60 Hz; 1152 x 864 at 75 Hz; 1024 x 768 at 60, 65, 70 or 75 Hz; 832 x 624 at 75 Hz (Mac); 800 x 600 at 56, 60, 72 or 75 Hz; 720 x 400 at 70 Hz; 720 x 350 at 70 Hz; 640 x 480 at 60, 66, 72 or 75 Hz
Power Consumption
48 W
Power Supply
External Power Adapter; efficiency Rating: CAT: V
Resolution
1280 x 1024 at 60 Hz
Response Time
20 msec
Speakers
2 Watt/Channel Speakers Located in Display Head
Stand Options
Tilt; Removable
Storage Temperature
-20 to 60 deg C
Touch Interface
USB: E762408, E680400, E314131, E850529
Viewing Angle
Horizontal: ±89 deg or 178 deg Total; Vertical: ±89 deg or 178 deg Total
The fully featured 1928L touch monitor offers best in class optical performance mated to the leading touch technologies–IntelliTouch surface acoustical wave and AccuTouch five-wire resistive–along with a combination touch controller, DVI, VGA and built-in speakers.
