OEM#: 9210-5137New OEM Original Outright

5P RACKMOUNT UPS SYSTEM by Eaton

Your price:
$1,075.57 eachReady to ship
HomeEaton92105137
5P RACKMOUNT UPS SYSTEM by Eaton
5P RACKMOUNT UPS SYSTEM by Eaton

OEM#: 9210-5137
5P RACKMOUNT UPS SYSTEM by Eaton

New OEM Original Outright
Your price:
$1,075.57 each

UPS System, Rack Mounting Style

Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
  • Manageability
    The graphical LCD display provides clear information on the UPS's status and measurements on a single screen (in seven languages). Enhanced configuration capabilities are also available with easy-to-use navigation keys. Load segment control enables prioritized shutdowns of nonessential equipment during outages in order to maximize battery runtime for critical devices. Load segment control can also be used to remotely reboot locked-up network equipment or to manage scheduled shutdowns and sequential start-ups.
  • Performance and efficiency
    Energy efficient UPS: with an optimized electrical design, the 5P provides up to 98% efficiency, reducing cooling and utility costs.
  • Pure sinewave output
    When operating in battery mode, the 5P provides a high quality output signal for any sensitive equipment connected, such as active PFC (power factor corrected) servers.
  • Adjustable tolerance and sensitivity
    Users can maximize useful battery life by widening the input voltage window or adjustable input waveform sensitivity (via the LCD or software) to adapt the UPS to a specific environment (like Genset).
  • Stronger, longer battery life
    Eaton ABM battery management technology uses an innovative three-stage charging technique that extends batteries by up to 50%.
Technical Specs
P/N: 9210-5137 Key Specs
Item
5P RACKMOUNT UPS SYSTEM
OEM
Eaton
OEM #
9210-5137
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
BTU Rating
Online: 106; Battery 500
Chemistry
Sealed Lead Acid
Communication
RS 232
Cord Length
6 ft
Efficiency
0.97
Expansion Slot
One slot; Gigabit Network Card (Network-M2) is optional
Feed Type
1
Frequency Rating
50 to 60 Hz
Height
1.7 in
Length
20 in
Noise Level
<45 dB at 1 meter
Package Quantity
1
Power Factor
0.77
Receptacle
(5) 5-15R
Relative Humidity
0-90% non-condensing
RoHS Compliant
Yes
Software Compatibility
Eaton Intelligent Power Manager
Standards and Approvals
cULus Listed; UL 1778; IEC 62040-2 C1-C2 / EN 55024 / CISPR22 Class B / FCC part 15 Class B; UL 497A
Temperature Range
0 to 35 deg C
Topology
Line-interactive
UPC
743172043054
User Interface
LCD graphical display
VA Rating
1000 VA
Voltage Rating
120 V
Wattage
770 W
Waveform
Sine Wave
Weight
32.5 lb
Width
17.4 in
