OEM#: 9210-3363New OEM Original Outright

7133R EATON(U) IEC 850VA 230/230VAC by Eaton

Your price:
$1,102.90 each
$1,130.48 Savings: $27.58 (2%)
Ready to ship
HomeEaton92103363
7133R EATON(U) IEC 850VA 230/230VAC by Eaton
7133R EATON(U) IEC 850VA 230/230VAC by Eaton
7133R EATON(U) IEC 850VA 230/230VAC by Eaton
7133R EATON(U) IEC 850VA 230/230VAC by Eaton

OEM#: 9210-3363
7133R EATON(U) IEC 850VA 230/230VAC by Eaton

New OEM Original Outright
Your price:
$1,102.90 each
$1,130.48 Savings: $27.58 (2%)

Eaton 5P is an energy efficient line-interactive UPS with advanced LCD and energy metering features

Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
  • Manageability
    The graphical LCD display provides clear information on the UPS's status and measurements on a single screen (in seven languages). Enhanced configuration capabilities are also available with easy-to-use navigation keys. Load segment control enables prioritized shutdowns of nonessential equipment during outages in order to maximize battery runtime for critical devices. Load segment control can also be used to remotely reboot locked-up network equipment or to manage scheduled shutdowns and sequential start-ups.
  • Performance and efficiency
    Energy efficient UPS: with an optimized electrical design, the 5P provides up to 98% efficiency, reducing cooling and utility costs.
  • Pure sinewave output
    When operating in battery mode, the 5P provides a high quality output signal for any sensitive equipment connected, such as active PFC (power factor corrected) servers.
  • Adjustable tolerance and sensitivity
    Users can maximize useful battery life by widening the input voltage window or adjustable input waveform sensitivity (via the LCD or software) to adapt the UPS to a specific environment (like Genset).
  • Stronger, longer battery life
    Eaton ABM battery management technology uses an innovative three-stage charging technique that extends batteries by up to 50%.
Features
  • Adjustable tolerance and sensitivity
  • Flexibility
  • Manageability
  • Performance and efficiency
  • Pure sinewave output
  • Stronger, longer battery life
Technical Specs
P/N: 9210-3363 Key Specs
Item
7133R EATON(U) IEC 850VA 230/230VAC
OEM
Eaton
OEM #
9210-3363
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Device Type
UPS - rack-mountable
Dimensions (WxDxH)
17.2 in x 20 in x 1.7 in
Environmental Standards
ENERGY STAR
Included Accessories
Rack mounting rails
Input Connectors
Power IEC 60320 C14
Input Voltage
AC 208/230 V
Load Rating
Small workgroup server
Networking
RS-232, USB
Output Voltage
AC 208/230 V
Output connectors
4 x power IEC 60320 C13
Power Capacity
600 Watt / 850 VA
Rack Size
1U
Weight
30.42 lbs
