OEM#: 1570-1017-NDNew OEM Original Outright

120 X 38 MM AXIAL FAN, 115V AC by Digi-Key

Your price:
$46.43 eachReady to ship
HomeDigi-Key15701017ND
120 X 38 MM AXIAL FAN, 115V AC by Digi-Key
120 X 38 MM AXIAL FAN, 115V AC by Digi-Key

OEM#: 1570-1017-ND
120 X 38 MM AXIAL FAN, 115V AC by Digi-Key

New OEM Original Outright
Your price:
$46.43 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 1570-1017-ND Key Specs
Item
120 X 38 MM AXIAL FAN, 115V AC
OEM
Digi-Key
OEM #
1570-1017-ND
Condition
New OEM Original
Returnable
No
Warranty
As Is
Air Flow
175 m³/hr
Amps
0.15 A
Bearing Type
Ball
Blade Material
Metal
Certifications
CE, cUL, TUV, UL
Current Rating
0.15 A
Fan Speed
3100 RPM
Fan Type
Tube axial
Flow Rating
103 CFM
Frame Material
Aluminum
Length
120 MM
Material
Aluminum
Noise
46 dBA
Noise Level
46 DBA
Operating Temperature
-40 - 90° C
Operating Temperature Range
-40°C - 90°C (-40°F- 194°F)
Power Rating
13 W
RPM
3100 RPM
Static Pressure
0.2400 in H2O (0.4484 Torr)
Termination Style
2
Voltage Rating
115 VAC
Watts
13 W
Width
38 MM
