OEM#: LFB-250PNew OEM Original Outright

SHEAR BEAM LOAD CELL - NICKLE PLATED ALLOY STEEL by Detecto Scale / Cardinal Scale

Your price:
$499.94 eachReady to ship
HomeDetecto Scale / Cardinal ScaleLFB250P
SHEAR BEAM LOAD CELL - NICKLE PLATED ALLOY STEEL by Detecto Scale / Cardinal Scale
SHEAR BEAM LOAD CELL - NICKLE PLATED ALLOY STEEL by Detecto Scale / Cardinal Scale

OEM#: LFB-250P
SHEAR BEAM LOAD CELL - NICKLE PLATED ALLOY STEEL by Detecto Scale / Cardinal Scale

New OEM Original Outright
Your price:
$499.94 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
  • 250 lb capacity rating
  • Alloy steel with nickle plated construction
  • Environmentally sealed with IP67 protection class
  • 2 mV/V output
  • Load cell cable length 67 inches
  • 1 year limited warranty
  • Safe overload up to 150% capacity
    • Features
    • Environmentally sealed with IP67 protection class
    • Safe overload up to 150% capacity
    Technical Specs
    P/N: LFB-250P Key Specs
    Item
    SHEAR BEAM LOAD CELL - NICKLE PLATED ALLOY STEEL
    OEM
    Detecto Scale / Cardinal Scale
    OEM #
    LFB-250P
    Condition
    New OEM Original
    Returnable
    No
    Warranty
    90 Day
    Capacity
    250 LB
    Country of Origin
    Spain
    Excitation Terminal Resistance
    375 - 414 ohms
    Finish
    Nickel Plated
    Full Scale Output
    2 mV/V
    IP Rating
    IP67
    Insulation Resistance
    5000 megohms
    Material
    Alloy Steel
    Recommended Excitation Voltage
    10 VDC (maximum of 15 V)
    Signal Terminal Resistance
    350 ± 5 ohms
    Standards
    OIML R60/1991-DK-00.02, VCAP
