OEM#: 7YR72New OEM Original Outright

STEEL 35.4 DIA 40.25 H ROOF FAN W.MOTOR by DAYTON ELECTRIC MANUFACTURING CO

Your price:
$5,637.65 eachReady to ship
HomeDAYTON ELECTRIC MANUFACTURING CO7yr72
STEEL 35.4 DIA 40.25 H ROOF FAN W.MOTOR by DAYTON ELECTRIC MANUFACTURING CO
STEEL 35.4 DIA 40.25 H ROOF FAN W.MOTOR by DAYTON ELECTRIC MANUFACTURING CO

OEM#: 7YR72
STEEL 35.4 DIA 40.25 H ROOF FAN W.MOTOR by DAYTON ELECTRIC MANUFACTURING CO

New OEM Original Outright
Your price:
$5,637.65 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 7YR72 Key Specs
Item
STEEL 35.4 DIA 40.25 H ROOF FAN W.MOTOR
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
7YR72
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Assembly
Unassembled
Base Height
6 1/4 in
Base Size - Roof Ventilators
29-1/8 in x 29-1/8 in
Bearing Type
Regreasable Pillow Block
CFM @ 0.000-In. SP
4477
CFM @ 0.125-In. SP
4348
CFM @ 0.250-In. SP
4224
CFM @ 0.375-In. SP
4108
CFM @ 0.500-In. SP
4005
CFM @ 0.625-In. SP
3904
CFM @ 0.750-In. SP
3703
CFM @ 0.875-In. SP
3515
CFM @ 1.000-In. SP
3336
CFM @ 1.250-In. SP
2841
Dimension A
29 1/8 in
Dimension B
35 3/8 in
Dimension C
34 in
Dimension D
21 in
Drive Package With Motor Included
Yes
Drive Type - Roof Ventilators
Belt Drive
Duty Rating - Roof Ventilators
Severe
Fixed Severe Duty 24"H Roof Curb Item No.
2EUG9
Housing Material
Steel
Hz
60
Includes
NEMA 1 Junction Box, Drive Package
Item - Roof Ventilators
Upblast Ventilator
Max. BHP
1.04
Max. Inlet Temp.
400 Degrees
Max. Operating Amps
3.6-3.8/1.9
Motor HP - Roof Ventilators
1 hp
Mounting Location - Roof Ventilators
Roof
Number of Speeds
1
Overall Dia.
35 3/8 in
Overall Height
40 1/4 in
Phase
3
RPM
1185
Requires
Roof Curb for New Installations
Shaft Dia. Wheel End
1 in
Sones @ 0.125 in SP @ 5 ft
17.9
Sones @ 0.250 in SP @ 5 ft
17.1
Sones @ 0.500 in SP @ 5 ft
16.5
Speed Controllable
No
Standards
UL/cUL 762, AMCA Sound and Air
Voltage - Roof Ventilators
208V AC/230V AC/460V AC
Wheel Dia.
18 1/2 in
Wheel Material
Steel
