OEM#: 7J358New OEM Original Outright

TUBEAXIAL FAN, DRIVE TYPE BELT DRIVE, INCLUDES DRIVE PACKAGE YES, INCLUDES MOTOR YES, BLADE DIAMETER 30 IN, NAMEPLATE VOLTAGE 208-230/460V A by DAYTON ELECTRIC MANUFACTURING CO

Your price:
$4,266.90 eachReady to ship
HomeDAYTON ELECTRIC MANUFACTURING CO7j358
TUBEAXIAL FAN, DRIVE TYPE BELT DRIVE, INCLUDES DRIVE PACKAGE YES, INCLUDES MOTOR YES, BLADE DIAMETER 30 IN, NAMEPLATE VOLTAGE 208-230/460V A by DAYTON ELECTRIC MANUFACTURING CO
TUBEAXIAL FAN, DRIVE TYPE BELT DRIVE, INCLUDES DRIVE PACKAGE YES, INCLUDES MOTOR YES, BLADE DIAMETER 30 IN, NAMEPLATE VOLTAGE 208-230/460V A by DAYTON ELECTRIC MANUFACTURING CO

OEM#: 7J358
TUBEAXIAL FAN, DRIVE TYPE BELT DRIVE, INCLUDES DRIVE PACKAGE YES, INCLUDES MOTOR YES, BLADE DIAMETER 30 IN, NAMEPLATE VOLTAGE 208-230/460V A by DAYTON ELECTRIC MANUFACTURING CO

New OEM Original Outright
Your price:
$4,266.90 each

TUBEAXIAL FAN, DRIVE TYPE BELT DRIVE, INCLUDES DRIVE PACKAGE YES, INCLUDES MOTOR YES, BLADE DIAMETER 30 IN, NAMEPLATE VOLTAGE 208-230/460V AC, PHASE 3, MOTOR HORSEPOWER 3/4 HP, AIRFLOW @ 0.000 IN SP 8,940 CFM, MAXIMUM NOISE LEVEL @ 5 FEET 24 SONES, ASSEMBLY UNASSEMBLED, FOR AIR TYPE EMERGENCY SMOKE, BLADE MATERIAL STEEL, HOUSING MATERIAL STEEL, NUMBER OF BLADES 6, NUMBER OF SPEEDS 1, MOTOR ENCLOSURE TOTALLY ENCLOSED FAN COOLED, STANDARDS AMCA, CU

Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 7J358 Key Specs
Item
TUBEAXIAL FAN, DRIVE TYPE BELT DRIVE, INCLUDES DRIVE PACKAGE YES, INCLUDES MOTOR YES, BLADE DIAMETER 30 IN, NAMEPLATE VOLTAGE 208-230/460V A
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
7J358
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Assembly
Unassembled
Bearing Type
Ball
Blade Dia.
30 in
Blade Material
Steel
Bolt Circle Dia.
5/16 in
CFM @ 0.000-In. SP
8,940 cfm
CFM @ 0.125-In. SP
8,257 cfm
CFM @ 0.250-In. SP
7,463 cfm
Dimension A
33 5/8 in
Dimension B
19 1/4 in
Dimension C
30 1/2 in
Dimension D
24 in
Dimension E
5/16 in
Drive Type
Belt-Drive
Fan RPM
841
Full Load Amps
2.8-2.8/1.4
Height
46 5/8 in
Housing Dia. w/Mtg. Flange
33 5/8 in
Housing Dia. w/o Mtg. Flange
30 1/2 in
Housing Finish
Baked Enamel
Housing Material
Steel
Hz
1.2
Includes
Belt Guard
Inlet Dia.
30 5/8 in
Max. Ambient Temp.
200 Degrees F
Max. BHP
0.718 hp
Max. Depth
24 in
Max. Inlet Temp.
1000 Degrees F for 15 min, 500 Degrees F for 4 hr
Max. Motor Height
10 in
Motor Enclosure
Totally Enclosed Fan-Cooled
Motor HP
3/4 hp
Motor RPM
1,725 RPM
Motor Type
3-Phase
Mounting Position
Vertical/Horizontal
Number of Blades
6
Outlet Dia.
30 5/8 in
Phase
3
Shaft Dia.
1 3/16 in
Sones @ 0.250-In. SP @ 5 Ft.
24
Standards
AMCA, cULus
Voltage
208-230/460
Width
33 41/64 in
