OEM#: 7CF77New OEM Original Outright

STEEL 35.4 DIA 38 H ROOF FAN W.MOTOR by DAYTON ELECTRIC MANUFACTURING CO

Your price:
$3,536.19 eachReady to ship
HomeDAYTON ELECTRIC MANUFACTURING CO7cf77
STEEL 35.4 DIA 38 H ROOF FAN W.MOTOR by DAYTON ELECTRIC MANUFACTURING CO
STEEL 35.4 DIA 38 H ROOF FAN W.MOTOR by DAYTON ELECTRIC MANUFACTURING CO

OEM#: 7CF77
STEEL 35.4 DIA 38 H ROOF FAN W.MOTOR by DAYTON ELECTRIC MANUFACTURING CO

New OEM Original Outright
Your price:
$3,536.19 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 7CF77 Key Specs
Item
STEEL 35.4 DIA 38 H ROOF FAN W.MOTOR
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
7CF77
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Assembly
Unassembled
Base Size - Roof Ventilators
40 1/2 in x 40 1/2 in
Bearing Size (in)
1 in
Bearing Type
Regreasable Pillow Block
Blade Dia.
36 in
CFM @ 0.000-In. SP
9,043 cfm
CFM @ 0.125-In. SP
7,643 cfm
CFM @ 0.250-In. SP
6,450 cfm
CFM @ 0.375-In. SP
3,880 cfm
Dimension A
40 1/2 in
Dimension B
68 in
Dimension C
60 in
Dimension D
38 in
Dimension E
22 in
Dimension F
7 1/2 in
Drive Type - Roof Ventilators
Belt Drive
Fan RPM
556
Frame Material
Galvanized Steel
Full Load Amps
8.0/4.0-4.0
Hz
60 Hz
Includes
Hood and Drive Package
Item - Roof Ventilators
Exhaust Ventilator
Max. Ambient Temp. (F)
104 Degrees F
Max. BHP
0.6 hp
Max. Depth (In.)
60 in
Max. Inlet Temp. (Deg. F)
104 Degrees F
Motor Enclosure
Totally Enclosed Air-Over
Motor HP - Roof Ventilators
1/2 hp
Motor RPM
1,725 RPM
Motor Type
Capacitor-Start
Mounting Position
Horizontal
Number of Blades
6
Overall Height - Roof Ventilators
38 in
Overall Width - Roof Ventilators
68 in
Phase
1
Propeller Material
Steel
Recommended 12 3/8"H Roof Curb Item No.
2ZV84
Recommended 6 3/8"H Roof Curb Item No.
4C455
Recommended Gravity Backdraft Damper Item No.
3HHN1
Shaft Dia. (In.)
1 in
Style - Roof Ventilators
Hooded
Voltage - Roof Ventilators
115V AC/208-230V AC
