OEM#: 7CF22New OEM Original Outright

STD DUTY FAN 18 408 CFM 115/208-230V by DAYTON ELECTRIC MANUFACTURING CO

Your price:
$1,768.85 eachReady to ship
HomeDAYTON ELECTRIC MANUFACTURING CO7cf22
STD DUTY FAN 18 408 CFM 115/208-230V by DAYTON ELECTRIC MANUFACTURING CO
STD DUTY FAN 18 408 CFM 115/208-230V by DAYTON ELECTRIC MANUFACTURING CO

OEM#: 7CF22
STD DUTY FAN 18 408 CFM 115/208-230V by DAYTON ELECTRIC MANUFACTURING CO

New OEM Original Outright
Your price:
$1,768.85 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 7CF22 Key Specs
Item
STD DUTY FAN 18 408 CFM 115/208-230V
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
7CF22
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Aluminum Wall Shutter Number
3C311
Assembly
Unassembled
Bearing Size
1-1/4 in
Bearing Type
Regreasable Pillow Block
Blade Diameter
42 in
CFM @ 0.000 in SP
18,408
CFM @ 0.125 in SP
16,388
CFM @ 0.250 in SP
13,752
Drive Package With Motor Included
Yes
Exhaust/Supply Fan Item
Exhaust Fan
Exhaust/Supply Fan Motor HP
1
Fan RPM
533
Fan Voltage
115/208-230 V AC
Fiberglass Wall Shutter Number
5C219
Flange Depth
2 in
Flange Width
46 in
Frame Material
Galvanized Steel
Full Load Amps
13.6/6.9-6.9
Galvanized Wall Shutter Number
1C210
Height
46 in
Hz
60
Includes
Drive Package
Intake Guard Number
1WBU6
Max BHP
1.2
Max Depth
23-1/2 in
Max Inlet Temperature
104 Degrees F
Motor Enclosure
Open Dripproof
Motor Insulation
Class B
Motor RPM
1725
Motor Type
Capacitor-Start
Motorized Wall Galv. Shutter Stock Number
3C730
Mounting Position
Horizontal or Vertical
Number of Blades
6
Phase
1
Propeller Material
Galvanized Steel
Shaft Diameter
1-1/4 in
Sones @ 0.000 in SP @ 5 feet
22
Sones @ 0.250 in SP @ 5 feet
21
Venturi Clearance Diameter
42-1/2 in
Venturi Depth
6 in
Wall Collar Stock Number
1WBV4
Weatherhood Number
1WBW3
Width (Inches)
46
