OEM#: 7C269New OEM Original Outright
BLOWER 22 5/8 IN by DAYTON ELECTRIC MANUFACTURING CO
Your price:
$5,282.40 each
OEM#: 7C269BLOWER 22 5/8 IN by DAYTON ELECTRIC MANUFACTURING CO
New OEM Original Outright
Your price:
$5,282.40 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 7C269 Key Specs
Item
BLOWER 22 5/8 IN
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
7C269
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bearing Type
Ball
Blower RPM
2185
CFM @ 10.00-In. SP
4900
CFM @ 11.00-In. SP
4475
CFM @ 12.00-In. SP
3985
CFM @ 13.00-In. SP
3260
CFM @ 4.000-In. SP
#
CFM @ 5.000-In. SP
#
CFM @ 6.000-In. SP
6200
CFM @ 7.000-In. SP
6050
CFM @ 8.000-In. SP
5665
CFM @ 9.000-In. SP
5270
Discharge Height (In.)
13
Discharge Width (In.)
10-1/2
Full Load Amps
47.2/23.6
Housing Finish
Gray Baked Polyester Epoxy
Housing Height (In.)
35-1/8
Housing Length (In.)
33-7/16
Housing Material
Steel
Housing Width (In.)
10-1/2
Hz
60
Includes
3C108, 3X611, 1103B, 683B, SK11116, SD158, 36VF08
Inlet Dia. (In.)
13-1/4
Max. Ambient Temp. (F)
104
Max. Inlet Temp. (Deg. F)
250
Motor Enclosure
Open Dripproof
Motor Frame
254T
Motor HP
20
Motor Insulation
Class F
Motor RPM
3530
Motor Type
Three Phase
Phase
3
Rotation
CW
Shaft Dia. (In.)
1 11/16
Type
With Drive Package
Voltage
230/460
Wheel Dia. (In.)
22-5/8
Wheel Material
Steel
Wheel Width (In.)
8-5/16
dBA @ 5 Feet
92
