OEM#: 7AG91New OEM Original Outright
BLOWER W/ DRIVE PKG 208-230/460 VOLT by DAYTON ELECTRIC MANUFACTURING CO
Your price:
$1,836.18 each $2,045.66 Savings: $209.48 (10%)
OEM#: 7AG91BLOWER W/ DRIVE PKG 208-230/460 VOLT by DAYTON ELECTRIC MANUFACTURING CO
New OEM Original Outright
Your price:
$1,836.18 each
$2,045.66 Savings: $209.48 (10%)
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 7AG91 Key Specs
Item
BLOWER W/ DRIVE PKG 208-230/460 VOLT
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
7AG91
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Assembly
Unassembled
Bearing Type
Ball
Blower RPM
1,116
CFM @ 0.125-In. SP
#
CFM @ 0.250-In. SP
1112
CFM @ 0.375-In. SP
1033
CFM @ 0.500-In. SP
954
CFM @ 0.750-In. SP
764 cfm
Depth (In.)
26 1/16 in
Discharge Height (In.)
10 3/4 in
Discharge Width (In.)
6 1/2 in
Full Load Amps
1.5-1.6/0.8
Height (In.)
18 3/4 in
Housing Finish
Gray Baked Polyester Epoxy
Housing Material
Steel
Hz
60/50
Includes
Weather Proof Drive Cover
Inlet Dia. (In.)
9 in
Max. Ambient Temp. (F)
104 Degrees F
Max. Inlet Temp. (Deg. F)
250 Degrees F
Motor Enclosure
Open Dripproof
Motor Frame
56
Motor HP
1/3 hp
Motor RPM
1,725 RPM
Motor Type
Three Phase
Phase
3
Rotation
CW
Shaft Dia. (In.)
3/4 in
Type
With Drive Package
Voltage
208-230/460
Wheel Dia. (In.)
9 in
Wheel Material
Steel
Wheel Width (In.)
4 1/2 in
Width (In.)
14 7/8 in
dBA @ 5 Feet
55
