OEM#: 7C319New OEM Original Outright
BLOWER 15 5/8 IN by DAYTON ELECTRIC MANUFACTURING CO
Your price:
$3,372.78 each
OEM#: 7C319BLOWER 15 5/8 IN by DAYTON ELECTRIC MANUFACTURING CO
New OEM Original Outright
Your price:
$3,372.78 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 7C319 Key Specs
Item
BLOWER 15 5/8 IN
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
7C319
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bearing Type
Ball
Blower RPM
2460
CFM @ 4.000-In. SP
2290
CFM @ 5.000-In. SP
2050
CFM @ 6.000-In. SP
1810
CFM @ 7.000-In. SP
1540
CFM @ 8.000-In. SP
1120
Discharge Height (In.)
9
Discharge Width (In.)
7-1/2
Full Load Amps
12.8/6.4
Housing Finish
Gray Baked Polyester Epoxy
Housing Height (In.)
24-3/8
Housing Length (In.)
23-7/8
Housing Material
Steel
Housing Width (In.)
7-1/2
Hz
60
Includes
1A107, 3C106, BK62, BK85, QT118, QT1316, 36VF05
Inlet Dia. (In.)
9-1/4
Max. Ambient Temp. (F)
104
Max. Inlet Temp. (Deg. F)
250
Motor Enclosure
Totally Enclosed
Motor Frame
184T
Motor HP
5
Motor Insulation
Class F
Motor RPM
1745
Motor Type
Three Phase
Phase
3
Rotation
CW
Shaft Dia. (In.)
1 3/16
Type
With Drive Package
Voltage
230/460
Wheel Dia. (In.)
15-5/8
Wheel Material
Steel
Wheel Width (In.)
5-7/8
dBA @ 5 Feet
79
