OEM#: 7A569New OEM Original Outright

CENTRIFUGAL DOWNBLAST ROOF EXHAUST FAN, DRIVE TYPE BELT DRIVE, ASSEMBLY UNASSEMBLED, WHEEL DIAMETER 21 1/2 IN, BASE DIAMETER NOT APPLICABLE, by DAYTON ELECTRIC MANUFACTURING CO

Your price:
$2,412.48 eachReady to ship
HomeDAYTON ELECTRIC MANUFACTURING CO7A569
CENTRIFUGAL DOWNBLAST ROOF EXHAUST FAN, DRIVE TYPE BELT DRIVE, ASSEMBLY UNASSEMBLED, WHEEL DIAMETER 21 1/2 IN, BASE DIAMETER NOT APPLICABLE, by DAYTON ELECTRIC MANUFACTURING CO
CENTRIFUGAL DOWNBLAST ROOF EXHAUST FAN, DRIVE TYPE BELT DRIVE, ASSEMBLY UNASSEMBLED, WHEEL DIAMETER 21 1/2 IN, BASE DIAMETER NOT APPLICABLE, by DAYTON ELECTRIC MANUFACTURING CO

OEM#: 7A569
CENTRIFUGAL DOWNBLAST ROOF EXHAUST FAN, DRIVE TYPE BELT DRIVE, ASSEMBLY UNASSEMBLED, WHEEL DIAMETER 21 1/2 IN, BASE DIAMETER NOT APPLICABLE, by DAYTON ELECTRIC MANUFACTURING CO

New OEM Original Outright
Your price:
$2,412.48 each

CENTRIFUGAL DOWNBLAST ROOF EXHAUST FAN, DRIVE TYPE BELT DRIVE, ASSEMBLY UNASSEMBLED, WHEEL DIAMETER 21 1/2 IN, BASE DIAMETER NOT APPLICABLE, BASE LENGTH 30 IN, BASE WIDTH 30 IN, BASE SHAPE SQUARE, NAMEPLATE VOLTAGE 115/208-230V AC, PHASE 1, MOTOR HORSEPOWER 1/2 HP, EXHAUST AIRFLOW @ 0.000 IN SP 4,261 CFM, FOR HIGH-STATIC PRESSURE APPLICATIONS NO, HIGH-EFFICIENCY MOTOR NO, FOR AIR TYPE CLEAN AIR, INCLUDES DRIVE PACKAGE YES, INCLUDES MOTOR YES, MOU

Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 7A569 Key Specs
Item
CENTRIFUGAL DOWNBLAST ROOF EXHAUST FAN, DRIVE TYPE BELT DRIVE, ASSEMBLY UNASSEMBLED, WHEEL DIAMETER 21 1/2 IN, BASE DIAMETER NOT APPLICABLE,
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
7A569
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Adj. 12 3/8"H Roof Curb Stock No.
3C437
Adj. 6 3/8"H Roof Curb Stock No.
4c454
Agency Compliance
AMCA Sound, Air, UL/cUL 705
Assembly
Unassembled
Base Height
1 3/4 in
Base Size - Roof Ventilators
30 in x 30 in
CFM @ 0.000-In. SP
4261
CFM @ 0.125-In. SP
4013
CFM @ 0.250-In. SP
3744
CFM @ 0.375-In. SP
3477
CFM @ 0.500-In. SP
3141
CFM @ 0.625-In. SP
2643
Dimension A
30 in
Dimension B
35 1/2 in
Dimension C
34 3/8 in
Dimension D
5 1/2 in
Drive Package With Motor Included
Yes
Drive Type - Roof Ventilators
Belt Drive
Duty Rating - Roof Ventilators
Standard
Housing Material
Spun Aluminum
Hz
60
Includes
4K259, 4L300, 4YU98, 1VP3412, QT34, AK74
Item - Roof Ventilators
Downblast Ventilator
Max. BHP
0.55
Max. Inlet Temp.
180 Degrees
Motor HP - Roof Ventilators
1/2 hp
Mounting Location - Roof Ventilators
Roof
Number of Speeds
1
Overall Dia.
35 1/2 in
Overall Height
29 3/4 in
Phase
1
RPM
770
Recommended 12 In. Fixed Curb Item No.
4HX49
Recommended 8 In. Fixed Curb Item No.
4HX41
Shaft Dia. Wheel End
3/4 in
Sones @ 0.125-In. SP @ 5 Ft.
11.0
Sones @ 0.250-In. SP @ 5 Ft.
10.7
Sones @ 0.500-In. SP @ 5 Ft.
9.8
Speed Controllable
No
Voltage - Roof Ventilators
115V AC/208V AC/230V AC
Wheel Dia.
21 1/2 in
Wheel Material
Aluminum
Wheel Type
Backward Inclined Centrifugal
