OEM#: 7A563New OEM Original Outright

ALU 35.5 DIA 36.2 H ROOF FAN W.MOTOR by DAYTON ELECTRIC MANUFACTURING CO

Your price:
$2,304.48 eachReady to ship
HomeDAYTON ELECTRIC MANUFACTURING CO7A563
ALU 35.5 DIA 36.2 H ROOF FAN W.MOTOR by DAYTON ELECTRIC MANUFACTURING CO
ALU 35.5 DIA 36.2 H ROOF FAN W.MOTOR by DAYTON ELECTRIC MANUFACTURING CO

OEM#: 7A563
ALU 35.5 DIA 36.2 H ROOF FAN W.MOTOR by DAYTON ELECTRIC MANUFACTURING CO

New OEM Original Outright
Your price:
$2,304.48 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 7A563 Key Specs
Item
ALU 35.5 DIA 36.2 H ROOF FAN W.MOTOR
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
7A563
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Adj. 12 3/8"H Roof Curb Stock No.
3C437
Adj. 6 3/8"H Roof Curb Stock No.
4c454
Agency Compliance
AMCA Sound, Air, UL/cUL 705
Assembly
Unassembled
Base Height
1 3/4 in
Base Size - Roof Ventilators
30 in x 30 in
CFM @ 0.000-In. SP
3150
CFM @ 0.125-In. SP
2997
CFM @ 0.250-In. SP
2832
CFM @ 0.375-In. SP
2624
CFM @ 0.500-In. SP
2375
CFM @ 0.625-In. SP
2053
Dimension A
30 in
Dimension B
35 1/2 in
Dimension C
34 3/8 in
Dimension D
5 1/2 in
Drive Package With Motor Included
Yes
Drive Type - Roof Ventilators
Belt Drive
Duty Rating - Roof Ventilators
Standard
Housing Material
Spun Aluminum
Hz
60
Includes
4K252, 4L290, 4YU97, BK75, 1VP3412, QT34
Item - Roof Ventilators
Downblast Ventilator
Max. BHP
0.35
Max. Inlet Temp.
180 Degrees
Motor HP - Roof Ventilators
1/3 hp
Mounting Location - Roof Ventilators
Roof
Number of Speeds
1
Overall Dia.
35 1/2 in
Overall Height
34 3/8 in
Phase
1
RPM
810
Recommended 12 In. Fixed Curb Item No.
4HX49
Recommended 8 In. Fixed Curb Item No.
4HX41
Shaft Dia. Wheel End
3/4 in
Sones @ 0.125-In. SP @ 5 Ft.
9.9
Sones @ 0.250-In. SP @ 5 Ft.
8.7
Sones @ 0.500-In. SP @ 5 Ft.
8.2
Speed Controllable
No
Voltage - Roof Ventilators
115V AC/208V AC/230V AC
Wheel Dia.
18 1/2 in
Wheel Material
Aluminum
Wheel Type
Backward Inclined Centrifugal
