OEM#: 6Z073New OEM Original Outright
AC GEARMOTOR 1.2 RPM OPEN 115V by DAYTON ELECTRIC MANUFACTURING CO
Your price:
$690.87 each
OEM#: 6Z073AC GEARMOTOR 1.2 RPM OPEN 115V by DAYTON ELECTRIC MANUFACTURING CO
New OEM Original Outright
Your price:
$690.87 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 6Z073 Key Specs
Item
AC GEARMOTOR 1.2 RPM OPEN 115V
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
6Z073
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bearings
Heavy Duty Needle on Case, Ball on Motor
Capacitor Required
2MDV3
Full Load Amps
0.3
Gear Case Material
Die Cast Aluminum
Gear Material
Steel or Heat Treated Powdered Metal
Gear Ratio
1369:1
Gear Type
Helical First Stage/Spur
Gearmotor Brake Type
None
Gearmotor Enclosure
Open
Gearmotor Mounting Position
All Angle
Gearmotor Phase
1
Gearmotor Rotation
CW/CCW
Gearmotor Shaft Orientation
Parallel
Gearmotor Shaft Type
Single
Gearmotor Type
AC Gearmotor
Gearmotor Voltage
115V AC
Gears
1st Stage Steel, Helical, Subsequent Stages Steel or Heat Treated Powdered Metal Spur
Housing
Die Cast Aluminum
Hz
60/50 Hz
Input HP
1/80 hp
Length Less Shaft
7 1/4 in
Lubrication
Permanent Heavy Duty Gear Oil
Max. Ambient Temp.
40 Degrees C
Maximum Torque
100.0 in-lb
Motor Type
PSC
Nameplate RPM
1.2 RPM
Overhung Load
90 lb
Seals
Spring Loaded Lip Type on Input and Output Shaft
Shaft Dia. (Dimension U)
1/2"
Shaft Length (Dimension V)
1"
Standards
UL Recognized, C-UL Recognized
Thermal Protection
Impedance
