OEM#: 6XJ53New OEM Original Outright
GP MTR CS TEFC 1-1/2 HP 3450 RPM 56H by DAYTON ELECTRIC MANUFACTURING CO
Your price:
$733.95 each
OEM#: 6XJ53GP MTR CS TEFC 1-1/2 HP 3450 RPM 56H by DAYTON ELECTRIC MANUFACTURING CO
New OEM Original Outright
Your price:
$733.95 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 6XJ53 Key Specs
Item
GP MTR CS TEFC 1-1/2 HP 3450 RPM 56H
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
6XJ53
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Country of Origin
Mexico
Duty
Continuous
Frame
56H
Full Load Amps
14.6/8.1-7.4
HP
1-1/2
Hz
60
Includes
Shaft Key
Ins. Class
B
Length Less Shaft
11 in
Max Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
Capacitor-Start/Run
Motor Efficiency Group
Energy Efficient
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Frame Material
Steel
Motor Mounting Position
All Angle
Motor Mounting Type
Rigid Base
Motor Service Factor
1
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
Auto
Nameplate RPM
3450
Nominal Efficiency
80.1 %
Number of Speeds
1
Overall Length
12-7/8 in
Phase
1
Shaft Diameter
5/8 in
Shaft Length
1-7/8 in
Standards
UL Recognized (E37403) and CSA Certification (258501)
Voltage
115/208-230
