OEM#: 5K586New OEM Original Outright

GP MTR SPLIT PH ODP 1/3 HP 3450 RPM 48 by DAYTON ELECTRIC MANUFACTURING CO

Your price:
$207.97 eachReady to ship
HomeDAYTON ELECTRIC MANUFACTURING CO5k586
GP MTR SPLIT PH ODP 1/3 HP 3450 RPM 48 by DAYTON ELECTRIC MANUFACTURING CO
GP MTR SPLIT PH ODP 1/3 HP 3450 RPM 48 by DAYTON ELECTRIC MANUFACTURING CO

OEM#: 5K586
GP MTR SPLIT PH ODP 1/3 HP 3450 RPM 48 by DAYTON ELECTRIC MANUFACTURING CO

New OEM Original Outright
Your price:
$207.97 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 5K586 Key Specs
Item
GP MTR SPLIT PH ODP 1/3 HP 3450 RPM 48
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
5K586
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Country of Origin
Mexico
Duty
Continuous
Frame
48Z
Full Load Amps
5.4
HP
1/3
Hz
60
Ins. Class
B
Length Less Shaft
8-7/16 in
Max Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
Split-Phase
Motor Efficiency Group
Standard Efficient
Motor Enclosure Design
Open Dripproof
Motor Frame Material
Rolled Steel
Motor Mounting Type
Cradle Base
Motor Service Factor
1.35
Motor Shaft Design
Flat
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
3450
Nominal Efficiency
53.3 %
Number of Speeds
1
Overall Length
10-5/16 in
Phase
1
Shaft Diameter
1/2 in
Shaft Length
1-7/8 in
Standards
CSA (156060), UL (E47479)
Voltage
115
