OEM#: 5RHT8New OEM Original Outright
BLOWER MOTOR 1/5 TO 3/4 HP 1075 RPM by DAYTON ELECTRIC MANUFACTURING CO
Your price:
$241.37 each
OEM#: 5RHT8BLOWER MOTOR 1/5 TO 3/4 HP 1075 RPM by DAYTON ELECTRIC MANUFACTURING CO
New OEM Original Outright
Your price:
$241.37 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 5RHT8 Key Specs
Item
BLOWER MOTOR 1/5 TO 3/4 HP 1075 RPM
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
5RHT8
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Application
Blowers, Fans and Air Circulators
Body Diameter
5-5/8 in
Bolt Circle Diameter
5-1/8 in
Capacitor Required
2MDV6, 2MDV7
Duty
Continuous
Frame
48YZ
Full Load Amps
8.7-2.4
HP
3/4 to 1/5
Hz
60
Ins. Class
B
Length Less Shaft
5-7/8 in
Max Ambient Temperature
60 Degrees C
Motor Application
HVAC/R
Motor Bearings
Ball
Motor Design
Permanent Split Capacitor
Motor Enclosure Design
Open Air-Over
Motor Mounting Position
All Angle
Motor Mounting Type
Stud
Motor Service Factor
1
Motor Shaft Design
Flat
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Direct Drive Fan/Blower
Motor Thermal Protection
Auto
Mounting Stud Pattern
3-5/8 in x 3-5/8 in
Nameplate RPM
1075
Nominal Efficiency
58 %
Number of Speeds
4
Overall Length
10-7/8 in
Phase
1
Resilient Ring Diameter
2-3/16 in
Ring to Ring Center
5-3/16 in
Shaft Diameter
1/2 in
Shaft Length
5 in
Standards
CSA Certified (244617), UL Recognized (E37403)
Voltage
115
Voltage Compatibility
115, 115/208-230, 115/230, 120, 120/240
