OEM#: 5K596New OEM Original Outright
GP MTR SPLIT PH TEFC 1/2 HP 1725 RPM 56 by DAYTON ELECTRIC MANUFACTURING CO
Your price:
$354.75 each
OEM#: 5K596GP MTR SPLIT PH TEFC 1/2 HP 1725 RPM 56 by DAYTON ELECTRIC MANUFACTURING CO
New OEM Original Outright
Your price:
$354.75 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 5K596 Key Specs
Item
GP MTR SPLIT PH TEFC 1/2 HP 1725 RPM 56
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
5K596
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Country of Origin
Mexico
Duty
Continuous
Frame
56
Full Load Amps
8
HP
1/2
Hz
60
Includes
Conduit Box
Ins. Class
F
Length Less Shaft
9-5/8 in
Max Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
Split-Phase
Motor Efficiency Group
Standard Efficient
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Frame Material
Rolled Steel
Motor Mounting Type
Rigid Base
Motor Service Factor
1
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
1725
Nominal Efficiency
63.9 %
Number of Speeds
1
Overall Length
11-1/2 in
Phase
1
Shaft Diameter
5/8 in
Shaft Length
1-7/8 in
Standards
CSA (156060), UL (E47479)
Voltage
115
