OEM#: 4ZJ45New OEM Original Outright
GEARMOTOR 8.3RPM 24VDC by DAYTON ELECTRIC MANUFACTURING CO
Your price:
$739.96 each
OEM#: 4ZJ45GEARMOTOR 8.3RPM 24VDC by DAYTON ELECTRIC MANUFACTURING CO
New OEM Original Outright
Your price:
$739.96 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 4ZJ45 Key Specs
Item
GEARMOTOR 8.3RPM 24VDC
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
4ZJ45
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bearings
Ball on Motor, Needle with Thrust Ball on Output Shaft
Brushes
Externally Replaceable
Full Load Amps
2.5 A
Gear Case
Die Cast Aluminum
Gear Ratio
216:1
Gear Type
Hardened Steel
Gearmotor Enclosure
Totally Enclosed Nonventilated
Gearmotor Mounting Position
All Angle
Gearmotor Rotation
CW/CCW
Gearmotor Shaft Orientation
Parallel
Gearmotor Shaft Type
Single
Gearmotor Type
DC Gearmotor
Input HP
1/8
Length Less Shaft
10 3/8 in
Lubrication
Permanent Heavy Fluid Gear Oil
Max. Ambient Temp.
40 Degrees C
Max. Torque
310.0 in-lb
Motor Type
Permanent Magnet DC
Nameplate RPM
8.3 RPM
Overhung Load
695 lb
Rear Shaft Encoder/Pulse Generator Mounting
Yes
Replacement Brushes
6YHY5
Seals
Spring Loaded Lip Type on Input and Output Shaft
Shaft Dia. (Dimension U)
3/4"
Shaft Length (Dimension V)
1"
Standards
C-UL Recognized, UL Recognized
Thermal Protection
None
