OEM#: 4Z143New OEM Original Outright

DC PERMANENT MAGNET MOTOR, MOTOR DESIGN PERMANENT MAGNET DC, 1/4, 1/7 HP, NAMEPLATE RPM 1,750/3,900, VOLTAGE 12/24V DC, 14.0 A FULL LOAD AMP by DAYTON ELECTRIC MANUFACTURING CO

Your price:
$378.91 eachReady to ship
HomeDAYTON ELECTRIC MANUFACTURING CO4z143
DC PERMANENT MAGNET MOTOR, MOTOR DESIGN PERMANENT MAGNET DC, 1/4, 1/7 HP, NAMEPLATE RPM 1,750/3,900, VOLTAGE 12/24V DC, 14.0 A FULL LOAD AMP by DAYTON ELECTRIC MANUFACTURING CO
DC PERMANENT MAGNET MOTOR, MOTOR DESIGN PERMANENT MAGNET DC, 1/4, 1/7 HP, NAMEPLATE RPM 1,750/3,900, VOLTAGE 12/24V DC, 14.0 A FULL LOAD AMP by DAYTON ELECTRIC MANUFACTURING CO

OEM#: 4Z143
DC PERMANENT MAGNET MOTOR, MOTOR DESIGN PERMANENT MAGNET DC, 1/4, 1/7 HP, NAMEPLATE RPM 1,750/3,900, VOLTAGE 12/24V DC, 14.0 A FULL LOAD AMP by DAYTON ELECTRIC MANUFACTURING CO

New OEM Original Outright
Your price:
$378.91 each

DC PERMANENT MAGNET MOTOR, MOTOR DESIGN PERMANENT MAGNET DC, 1/4, 1/7 HP, NAMEPLATE RPM 1,750/3,900, VOLTAGE 12/24V DC, 14.0 A FULL LOAD AMPS, NON-STANDARD FRAME, FULL LOAD TORQUE 5.6 IN-LB, MOTOR SERVICE FACTOR 1, MOTOR THERMAL PROTECTION NONE, INS. CLASS B, MAX. AMBIENT TEMP. 40 DEGREES C, MOTOR SHAFT ROTATION CW/CCW, DUTY CYCLE CONTINUOUS, MOTOR ENCLOSURE DESIGN TOTALLY ENCLOSED NONVENTILATED, MOTOR MOUNTING TYPE FACE/BASE, REMOVABLE BASE YES,

Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 4Z143 Key Specs
Item
DC PERMANENT MAGNET MOTOR, MOTOR DESIGN PERMANENT MAGNET DC, 1/4, 1/7 HP, NAMEPLATE RPM 1,750/3,900, VOLTAGE 12/24V DC, 14.0 A FULL LOAD AMP
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
4Z143
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Base Mounting O.C.
6-7/16 x 2 in
Bearings
Ball
Brush Type
External
Country of Origin
USA
Face Mounting O.C.
2-5/8 x 2-5/8
Frame
Non-Standard
Full Load Amps
14 A
Full Load Torque
5.63 in-lb
HP
1/7, 1/4
Ins. Class
B
Length Less Shaft
6-7/8 in
Max Ambient Temperature
40 Degrees C
Motor Application
Variable Speed
Motor Design
DC Permanent Magnet
Motor Enclosure Design
Totally Enclosed Nonventilated
Motor Mounting Type
Face/Base
Motor Thermal Protection
None
Nameplate RPM
1750/3900
Overall Length
8-3/8 in
Rotation
CW/CCW
Shaft Diameter
1/2 in
Shaft Length
1-1/2 in
Standards
UL Recognized (E61772)
Voltage
12/24V DC
Voltage Compatibility
12V DC, 24V DC
